Mini 20mNm NEMA 8 Stepper Motor 0.6A Casun Stepper Motor For Beauty Equipment

Mini 20mNm NEMA 8 Stepper Motor 0.6A Casun Stepper Motor For Beauty Equipment

Products - Hybrid Stepper Motor - NEMA 8 Stepper Motor
  • High Light

    0.6A Casun Stepper Motor

    ,

    Mini 20mNm NEMA 8 Stepper Motor

    ,

    Casun NEMA 8 Stepper Motor

  • Step Angel
    1.8°
  • Holding Torque
    20mN.m
  • Current
    0.6A
  • Motor Length
    33mm
  • Shaft
    Round Shaft 10mm Length
  • Place of Origin
    CHINA
  • Brand Name
    Casun
  • Certification
    CE,ROSH,ISO
  • Model Number
    20SHD0501-20
  • Minimum Order Quantity
    1PC
  • Price
    $5.94-$8.6
  • Packaging Details
    Carton:36x29x14cm
  • Delivery Time
    7-15 days
  • Payment Terms
    D/A, T/T, L/C, D/P
  • Supply Ability
    40000+PCS+Month

Mini 20mNm NEMA 8 Stepper Motor 0.6A Casun Stepper Motor For Beauty Equipment

  • Mini 20mNm NEMA 8 Stepper Motor 0.6A Casun Stepper Motor For Beauty Equipment
  • Mini 20mNm NEMA 8 Stepper Motor 0.6A Casun Stepper Motor For Beauty Equipment
  • Mini 20mNm NEMA 8 Stepper Motor 0.6A Casun Stepper Motor For Beauty Equipment
  • Mini 20mNm NEMA 8 Stepper Motor 0.6A Casun Stepper Motor For Beauty Equipment
Get Price Contact Now

20x20x33mm 0.6A Casun Stepper Motor Nema 8 Mini Stepper Motor For Medical beauty equipment

Motor Specifications



Step Angel



1.8 °

Fram Size



20 mm

Number of Phase



2 Phase

Rated Current



0.6 A

Holding Torque



20 mN.m

Resistance



5.8 ohm

Inductance



1.5 mH

Rotor Inertia



2.5 g-cm²

Motor weight



0.07 kg

Number of leads



4

Connection



Bipolar





Appearance

Mini 20mNm NEMA 8 Stepper Motor 0.6A Casun Stepper Motor For Beauty Equipment 0

Dimensions

Mini 20mNm NEMA 8 Stepper Motor 0.6A Casun Stepper Motor For Beauty Equipment 1



Torque Curves



















Download









If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Connector

Please click the "Get  a quote" button below to tell us your requirements.
