Casun Bipolar NEMA 14 Stepper Motor 35mm 12 Volt DC Stepper Motor

Casun Bipolar NEMA 14 Stepper Motor 35mm 12 Volt DC Stepper Motor

  • High Light

    Casun Bipolar NEMA 14 Stepper Motor

    ,

    35mm 12 Volt DC Stepper Motor

    ,

    Casun 12 Volt DC Stepper Motor

  • Step Angel
    1.8°
  • Holding Torque
    100mN.m
  • Current
    0.4A
  • Motor Length
    26mm
  • Shaft
    D Shaft 20mm Length
  • Place of Origin
    CHINA
  • Brand Name
    Casun
  • Certification
    CE,ROSH,ISO
  • Model Number
    35SHD0001-20
  • Minimum Order Quantity
    1PC
  • Price
    $4.14-$6.98
  • Packaging Details
    Carton:36x29x14cm
  • Delivery Time
    7-15 days
  • Payment Terms
    D/A, T/T, L/C, D/P
  • Supply Ability
    40000+PCS+Month

Casun Bipolar NEMA 14 Stepper Motor 35mm 12 Volt DC Stepper Motor

35X35x26mm 0.4A 2 Phase Bipolar Hybrid 12V DC NEMA 14 Thin Stepper Motor

The 35mm Hybrid Stepper Motor Series offers powerful holding torque in a variety of sizes.

Use with a microstepping driver to reduce vibration and achieve higher step resolution.

Choose a baseline version or request your own customized configuration.



Features:

  • Bipolar or unipolar versions available

  • Hybrid stepper construction

  • Available in single or double shaft versions

  • CE and RoHS approved

  • Customizations on request



Appearance

Casun Bipolar NEMA 14 Stepper Motor 35mm 12 Volt DC Stepper Motor 0

Dimensions

Casun Bipolar NEMA 14 Stepper Motor 35mm 12 Volt DC Stepper Motor 1







Motor Specifications



Step Angel



1.8 °

Fram Size



35 mm

Number of Phase



2 Phase

Rated Current



0.4A

Holding Torque



100 mN.m

Resistance



20 ohm

Inductance



20 mH

Rotor Inertia



12 g-cm²

Motor weight



0.15 kg

Number of leads



4

Connection



Bipolar









Torque Curves





Casun Bipolar NEMA 14 Stepper Motor 35mm 12 Volt DC Stepper Motor 2











Download









If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Connector

Please click the "Get  a quote" button below to tell us your requirements.
