Home > products > Hybrid Stepper Motor > 2Nm 2.8A 3.2V NEMA 23 Stepper Motor For Cnc Machine 57x57mm CNC Stepping Motor
2Nm 2.8A 3.2V NEMA 23 Stepper Motor For Cnc Machine 57x57mm CNC Stepping Motor
2Nm 2.8A 3.2V NEMA 23 Stepper Motor For Cnc Machine 57x57mm CNC Stepping Motor
2Nm 2.8A 3.2V NEMA 23 Stepper Motor For Cnc Machine 57x57mm CNC Stepping Motor
2Nm 2.8A 3.2V NEMA 23 Stepper Motor For Cnc Machine 57x57mm CNC Stepping Motor

2Nm 2.8A 3.2V NEMA 23 Stepper Motor For Cnc Machine 57x57mm CNC Stepping Motor

Product Details

Place of Origin: CHINA

Brand Name: Casun

Certification: CE,ROHS,ISO

Model Number: 57SHD4809-24

Payment & Shipping Terms

Minimum Order Quantity: 1PC

Price: $9.49-$14

Packaging Details: Carton:36x29x14cm

Delivery Time: 7-15 days

Payment Terms: D/A, T/T, L/C, D/P

Supply Ability: 40000+PCS+Month

Get Best Price

Product Details

Product Description
Product Details
High Light:

2.8A 3.2V NEMA 23 Stepper Motor

,

2Nm 2.8A NEMA 23 Stepper Motor

,

57x57mm CNC Stepping Motor

Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Product Description

The 57mm Hybrid Stepper Motor Series comes in a range of sizes and provides strong holding torque.

To lessen vibration and produce a greater step resolution, use with a microstepping driver.

Select a standard version or ask for a specially configured version.



Features:

  • Bipolar or unipolar versions available

  • Hybrid stepper construction

  • Available in single or double shaft versions

  • CE and RoHS approved

  • Customizations on request

Dimensions

2Nm 2.8A 3.2V NEMA 23 Stepper Motor For Cnc Machine 57x57mm CNC Stepping Motor 0







Motor Specifications



Step Angel



1.8 °

Fram Size



57 mm

Number of Phase



2 Phase

Rated Current



2.8A

Holding Torque



2000mN.m

Resistance



1.5hm

Inductance



5mH

Rotor Inertia



460 g-cm²

Motor weight



1 kg

Number of leads



4

Connection



Bipolar



Operating Specifications





Step Angle: 1.8°

Maximum  Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min









Torque Curves







Submodels



Model Holding Torque Step Angle Length Type of Shaft Rated Current
57SHD4013-21B 0.6N.m 1.8° 41mm D Shaft-21mm 1.0A
57SHD4415-21B 1.1N.m 1.8° 54mm D Shaft-21mm 3.0A
57SHD4816-21B 2.0N.m 1.8° 76mm D Shaft-21mm 3.0A
57SHD4913-21B 2.5N.m 1.8° 83mm D Shaft-21mm 3.0A
57SHD4934-20B 3.0N.m 1.8° 100mm D Shaft-20mm 3.0A



Download





If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
            Encoder          |               Brake           |              Gearbox            |           Shaft

2Nm 2.8A 3.2V NEMA 23 Stepper Motor For Cnc Machine 57x57mm CNC Stepping Motor 1 2Nm 2.8A 3.2V NEMA 23 Stepper Motor For Cnc Machine 57x57mm CNC Stepping Motor 2 2Nm 2.8A 3.2V NEMA 23 Stepper Motor For Cnc Machine 57x57mm CNC Stepping Motor 3 2Nm 2.8A 3.2V NEMA 23 Stepper Motor For Cnc Machine 57x57mm CNC Stepping Motor 4





Please click the "Get  a quote" button below to tell us your requirements.
