products details

Created with Pixso. Home Created with Pixso. Products Created with Pixso.
Hybrid Stepper Motor
Created with Pixso.

10mNm 4 Wire Bipolar Stepper Motor 5V 0.24A Nema 8 Motor 20x20x25mm

name

10mNm 4 Wire Bipolar Stepper Motor 5V 0.24A Nema 8 Motor 20x20x25mm

Brand Name: Casun
Model Number: B20SHD4701-14P
MOQ: 1PC
Price: $5.94-$8.6
Payment Terms: D/A, T/T, L/C, D/P
Supply Ability: 40000+PCS+Month
Detail Information
Product Description
Detail Information
Place of Origin:
CHINA
Certification:
CE,ROSH,ISO
Step Angel:
1.8°
Holding Torque:
10mN.m
Current:
0.24A
Motor Length:
24.8mm
Shaft:
Round Shaft 14mm Length
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Packaging Details:
Carton:36x29x14cm
Highlight:

10mNm 4 Wire Bipolar Stepper Motor

,

4 Wire Bipolar Stepper Motor 5V

,

5V 0.24A Nema 8 Motor

Product Description

Nema 8 Bipolar 1.8deg 10mN.m (1.42oz.in) Stepper Motor 0.24A 5.04V 20x20x25mm 4 Wires



Motor Specifications

Step Angel

1.8 °

Fram Size

20 mm

Number of Phase

2 Phase

Rated Current

0.24 A

Holding Torque

10 mN.m

Resistance

21 ohm

Inductance

5 mH

Rotor Inertia

2 g-cm²

Motor weight

0.08 kg

Number of leads

4

Connection

Bipolar

Appearance



10mNm 4 Wire Bipolar Stepper Motor 5V 0.24A Nema 8 Motor 20x20x25mm 0

Dimensions

10mNm 4 Wire Bipolar Stepper Motor 5V 0.24A Nema 8 Motor 20x20x25mm 1



Torque Curves



















Download







If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Connector

Please click the "Get  a quote" button below to tell us your requirements.
