Home > products > Hybrid Stepper Motor > 0.4A 12V Stepper Motor High Torque 110 MNm 12V Bipolar Stepper Motor
0.4A 12V Stepper Motor High Torque 110 MNm 12V Bipolar Stepper Motor
0.4A 12V Stepper Motor High Torque 110 MNm 12V Bipolar Stepper Motor
0.4A 12V Stepper Motor High Torque 110 MNm 12V Bipolar Stepper Motor
0.4A 12V Stepper Motor High Torque 110 MNm 12V Bipolar Stepper Motor
0.4A 12V Stepper Motor High Torque 110 MNm 12V Bipolar Stepper Motor
0.4A 12V Stepper Motor High Torque 110 MNm 12V Bipolar Stepper Motor
0.4A 12V Stepper Motor High Torque 110 MNm 12V Bipolar Stepper Motor

0.4A 12V Stepper Motor High Torque 110 MNm 12V Bipolar Stepper Motor

Product Details

Place of Origin: CHINA

Brand Name: Casun

Certification: CE,ROHS,ISO

Model Number: 35SHD0003-30

Payment & Shipping Terms

Minimum Order Quantity: 1PC

Price: $4.14-$6.98

Packaging Details: Carton:36x29x14cm

Delivery Time: 7-15 days

Payment Terms: D/A, T/T, L/C, D/P

Supply Ability: 40000+PCS+Month

Get Best Price

Product Details

Product Description
Product Details
High Light:

0.4A 12V Stepper Motor High Torque

,

12V Stepper Motor High Torque 110 mNm

,

Casun 12V Bipolar Stepper Motor

Step Angel:
1.8°
Holding Torque:
110mN.m
Current:
0.4A
Motor Length:
26mm
Shaft:
Round Shaft 30mm Length
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Step Angel:
1.8°
Holding Torque:
110mN.m
Current:
0.4A
Motor Length:
26mm
Shaft:
Round Shaft 30mm Length
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Product Description

The 35mm Hybrid Stepper Motor Series can quickly start and stop, suitable for applications that require quick response and action.

Use with a microstepping driver to reduce vibration and achieve higher step resolution.



Features:

  • Bipolar or unipolar versions available

  • Versions in unipolar or bipolar are offered

  • Available in variations with a single or double shaft

  • Deliver "multiple international certifications" for electrical and high-tech devices

  • Customizations on request





Motor Specifications

Step Angel

1.8 °

Fram Size

35 mm

Number of Phase

2 Phase

Rated Current

0.4 A

Holding Torque

110 mN.m

Resistance

30 ohm

Inductance

24 mH

Rotor Inertia

12 g-cm²

Motor weight

0.15 kg

Number of leads

4

Connection

Bipolar





Appearance



0.4A 12V Stepper Motor High Torque 110 MNm 12V Bipolar Stepper Motor 0

Dimensions

0.4A 12V Stepper Motor High Torque 110 MNm 12V Bipolar Stepper Motor 1





Torque Curves



















Download







If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Connector

Please click the "Get  a quote" button below to tell us your requirements.
