Hybrid Stepper Motor
Created with Pixso.

Motor paso a paso Stage Lighting NEMA 14 Hybrid Stepper Motor 0.32A 11.84V Casun Motor

name

Motor paso a paso Stage Lighting NEMA 14 Hybrid Stepper Motor 0.32A 11.84V Casun Motor

Brand Name: Casun
Model Number: P35SHD0184-24B
MOQ: 1PC
Price: $2.88-$5.64
Payment Terms: D/A, T/T, L/C, D/P
Supply Ability: 40000+PCS+Month
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
CE,ROHS,ISO
Step Angel:
1.8°
Holding Torque:
240mN.m
Current:
0.32A
Rated Voltage:
11.84V
Motor Length:
34mm
Shaft:
Milling Flat Shaft 24mm Length
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Packaging Details:
Carton:36x29x14cm
Highlight:

Stage Lighting NEMA 14

,

NEMA 14 Hybrid Stepper Motor

,

1.2A 4.8V Casun Motor

Product Description

Casun 0.32A 11.84V NEMA 14 Hybrid Stepper Motor for Stage Lighting, 35x35x34mm



Stepper Motor for Stage Lighting 35x35x34mm 1.8 Degree NEMA 14 Ordinary Model 0.24N.m



In a range of sizes, the 35mm Hybrid Stepper Motor Series provides strong holding torque.



To lessen vibration and achieve a greater step resolution, use with a microstepping driver.



Select a standard version or ask for a specially configured version.



Features:

  • Available in bipolar or unipolar forms.

  • Hybrid design for steppers.

  • Available in configurations with a single shaft or two shafts.

  • Certified by RoHS and CE.

  • On demand customizations.



Appearance



Motor paso a paso Stage Lighting NEMA 14 Hybrid Stepper Motor 0.32A 11.84V Casun Motor 0

Dimensions

Motor paso a paso Stage Lighting NEMA 14 Hybrid Stepper Motor 0.32A 11.84V Casun Motor 1



Motor Specifications

Step Angel

1.8 °

Fram Size

35 mm

Number of Phase

2 Phase

Rated Current

0.32 A

Holding Torque

240 mN.m

Resistance

37 ohm

Inductance

52 mH

Rotor Inertia

20 g-cm²

Motor weight

0.21 kg

Number of leads

4

Connection

Bipolar









Torque Curves



Download







If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

FAQ

1. who are we?

We are based in Guangdong, China, start from 2011,sell to Domestic Market(63.00%),Western Europe(12.00%),North America(9.00%),Eastern Asia(8.00%),Northern Europe(2.00%),Eastern Europe(00.00%),Southeast Asia(00.00%),Oceania(00.00%),Mid East(00.00%),Southern Europe(00.00%),South Asia(00.00%). There are total about 51-100 people in our office.



2. how can we guarantee quality?

Always a pre-production sample before mass production;

Always final Inspection before shipment;



3.what can you buy from us?

Stepper Motor,BLDC Motor



4. why should you buy from us not from other suppliers?

We are specialized in producing and selling stepper motors for more than 11 years.



5. what services can we provide?

Accepted Delivery Terms: FOB,CFR,CIF,EXW,Express Delivery；

Accepted Payment Currency:USD,CNY;

Accepted Payment Type: T/T,L/C,D/P D/A,,PayPal;

Language Spoken:English,Chinese,Japanese

Options:
         Encoder          |                 Brake            |               Gearbox          |         Connector

Motor paso a paso Stage Lighting NEMA 14 Hybrid Stepper Motor 0.32A 11.84V Casun Motor 2 Motor paso a paso Stage Lighting NEMA 14 Hybrid Stepper Motor 0.32A 11.84V Casun Motor 3 Motor paso a paso Stage Lighting NEMA 14 Hybrid Stepper Motor 0.32A 11.84V Casun Motor 4 Motor paso a paso Stage Lighting NEMA 14 Hybrid Stepper Motor 0.32A 11.84V Casun Motor 5

Please click the "Get  a quote" button below to tell us your requirements.
