120mNm 28*28*51mm Nema 11 Stepper Motor 0.67A Casun 6.16V Stepper Motor for medical equipment
-
Step Angel1.8°
-
Holding Torque120mN.m
-
Current0.67A
-
Motor Length51.5mm
-
ShaftMilling Flat Shaft 20mm Length
-
Place of OriginChina
-
Brand NameCasun
-
CertificationCE,ROHS,ISO
-
Model Number28SHD4501-20B
-
Minimum Order Quantity1PC
-
Price$5.94-$8.6
-
Packaging DetailsCarton:36x29x14cm
-
Delivery Time7-15 days
-
Payment TermsD/A, T/T, L/C, D/P
-
Supply Ability40000+PCS+Month
120mNm 28*28*51mm Nema 11 Stepper Motor 0.67A Casun 6.16V Stepper Motor for medical equipment
2 Phase 1.8 Degree NEMA 11 Micro Stepper Motor 28*28*51mm for Machine Robot Camera
The 28mm Hybrid Stepper Motor Series offers powerful holding torque in a variety of sizes.
Use with a microstepping driver to reduce vibration and achieve higher step resolution.
Choose a baseline version or request your own customized configuration.
Features:
-
Bipolar or unipolar versions available
-
Hybrid stepper construction
-
Available in single or double shaft versions
-
CE and RoHS approved
-
Customizations on request
Appearance
Dimensions
Motor Specifications
Step Angel |
1.8 ° |
Fram Size |
28 mm |
Number of Phase |
2 Phase |
Rated Current |
0.67 A |
Holding Torque |
120 mN.m |
Resistance |
9.2 ohm |
Inductance |
7.2 mH |
Rotor Inertia |
18 g-cm² |
Motor weight |
0.2 kg |
Number of leads |
4 |
Connection |
Bipolar |
Torque Curves
Download
If our standard motor cannot meet your needs,
we can customize the motor according to your needs
Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.
Options:
Encoder | Brake | Gearbox | Connector
Please click the "Get a quote" button below to tell us your requirements.
