High Light:
Bipolar Nema 8 Stepper Motor
, 3.6V Nema 8 Stepper Motor
, Micro Nema 8 Stepper Motor
Micro 20*20mm 0.8A Bipolar Nema 8 Stepper Motor 2 Phase 3.6V Stepper Motor for Video conference machine
2 Phase 3.6V Nema 8 Bipolar 1.8 degree Stepping Motor 20x20x33mm 21mN.m 4 wires 0.8A for Video conference machine
Appearance
Motor Specifications
Step Angel
|
1.8 °
|
Fram Size
|
20 mm
|
Number of Phase
|
2 Phase
|
Rated Current
|
0.8 A
|
Holding Torque
|
21 mN.m
|
Resistance
|
4.5 ohm
|
Inductance
|
1.6 mH
|
Rotor Inertia
|
2.5 g-cm²
|
Motor weight
|
0.07 kg
|
Number of leads
|
4
|
Connection
|
Bipolar
|
Torque Curves
Download
If our standard motor cannot meet your needs,
we can customize the motor according to your needs
Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.
FAQ
1. who are we?
We are based in Guangdong, China, start from 2011,sell to Domestic Market(63.00%),Western Europe(12.00%),North America(9.00%),Eastern Asia(8.00%),Northern Europe(2.00%),Eastern Europe(00.00%),Southeast Asia(00.00%),Oceania(00.00%),Mid East(00.00%),Southern Europe(00.00%),South Asia(00.00%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Stepper Motor,BLDC Motor
4. why should you buy from us not from other suppliers?
We are specialized in producing and selling stepper motors for more than 11 years.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,Express Delivery；
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,,PayPal;
Language Spoken:English,Chinese,Japanese
Options:
Encoder | Brake | Gearbox | Connector
Please click the "Get a quote" button below to tell us your requirements.
