NEMA 23 Hybrid Stepper Motor 57*57*54mm 2.0A 1.2N.M With CE ROHS

name

NEMA 23 Hybrid Stepper Motor 57*57*54mm 2.0A 1.2N.M With CE ROHS

Brand Name: Casun
Model Number: 57SHD4407-30B
MOQ: 1PC
Price: $3.14-$5
Payment Terms: D/A, T/T, L/C, D/P
Supply Ability: 40000+PCS+Month
Detail Information
Product Description
Detail Information
Place of Origin:
CHINA
Certification:
CE,ROHS,ISO
Step Angel:
1.8°
Holding Torque:
1200mN.m
Current:
2.0A
Motor Length:
54mm
Shaft:
Milling Flat Shaft 30mm Length
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Packaging Details:
Carton:36x29x14cm
Highlight:

NEMA 23 Hybrid Stepper Motor

,

Hybrid Stepper Motor 2.0A

Product Description

There will be no out of step phenomenon and no additional feedback control is required, with excellent static and dynamic stability.

Only when it needs to rotate will it consume electricity, and the power consumption in standby mode is very low, saving energy.



Features:

  • High accuracy and torque

  • For electronic industrial equipment and high-tech industry equipment

  • Within 48 hours, one of our engineers will contact you with the best option

  • With a 12-year history in China and more than 800 clients served

  • High accuracy and torque





Motor Specifications



Step Angel

1.8 °

Fram Size

57 mm

Number of Phase

2 Phase

Rated Current

2.0 A

Holding Torque

1200 mN.m

Resistance

1.4 ohm

Inductance

5.0 mH

Rotor Inertia

260 g-cm²

Motor weight

0.6 kg

Number of leads

4

Connection

Bipolar

Appearance

NEMA 23 Hybrid Stepper Motor 57*57*54mm 2.0A 1.2N.M With CE ROHS 0

Dimensions

NEMA 23 Hybrid Stepper Motor 57*57*54mm 2.0A 1.2N.M With CE ROHS 1


Operating Specifications

Step Angle: 1.8°

Maximum  Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min







Torque Curves













Submodels



Model Holding Torque Step Angle Length Type of Shaft Rated Current
57SHD4013-21B 0.6N.m 1.8° 41mm D Shaft-21mm 1.0A
57SHD4415-21B 1.1N.m 1.8° 54mm D Shaft-21mm 3.0A
57SHD4816-21B 2.0N.m 1.8° 76mm D Shaft-21mm 3.0A
57SHD4913-21B 2.5N.m 1.8° 83mm D Shaft-21mm 3.0A
57SHD4934-20B 3.0N.m 1.8° 100mm D Shaft-20mm 3.0A



Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:

Encoder

Brake

Gearbox

Shaft
NEMA 23 Hybrid Stepper Motor 57*57*54mm 2.0A 1.2N.M With CE ROHS 2 NEMA 23 Hybrid Stepper Motor 57*57*54mm 2.0A 1.2N.M With CE ROHS 3 NEMA 23 Hybrid Stepper Motor 57*57*54mm 2.0A 1.2N.M With CE ROHS 4 NEMA 23 Hybrid Stepper Motor 57*57*54mm 2.0A 1.2N.M With CE ROHS 5



Please click the "Get a quote" button below to tell us your requirements.
