Home > products > High Temp Stepper Motor > 42x42x48mm 1.8 Degree High Temp Stepper Motor 0.59N.M 2.8A CE ROHS
42x42x48mm 1.8 Degree High Temp Stepper Motor 0.59N.M 2.8A CE ROHS
42x42x48mm 1.8 Degree High Temp Stepper Motor 0.59N.M 2.8A CE ROHS
42x42x48mm 1.8 Degree High Temp Stepper Motor 0.59N.M 2.8A CE ROHS
42x42x48mm 1.8 Degree High Temp Stepper Motor 0.59N.M 2.8A CE ROHS
42x42x48mm 1.8 Degree High Temp Stepper Motor 0.59N.M 2.8A CE ROHS
42x42x48mm 1.8 Degree High Temp Stepper Motor 0.59N.M 2.8A CE ROHS

42x42x48mm 1.8 Degree High Temp Stepper Motor 0.59N.M 2.8A CE ROHS

Product Details

Place of Origin: CHINA

Brand Name: Casun

Certification: CE,ROSH,ISO

Model Number: G42SHD4425-24BH

Payment & Shipping Terms

Minimum Order Quantity: 1PC

Price: $3.14-$5

Packaging Details: Carton:36x29x14cm

Delivery Time: 7-15 days

Payment Terms: D/A, T/T, L/C, D/P

Supply Ability: 40000+PCS+Month

Get Best Price

Product Details

Product Description
Product Details
High Light:

1.8 Degree High Temp Stepper Motor

,

High Temp Stepper Motor 2.8A

Step Angel:
1.8°
Holding Torque:
590mN.m
Current:
2.8A
Motor Length:
48mm
Shaft:
Milling Flat Shaft 24mm Length
Insulation Class:
Class H (180℃)
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Step Angel:
1.8°
Holding Torque:
590mN.m
Current:
2.8A
Motor Length:
48mm
Shaft:
Milling Flat Shaft 24mm Length
Insulation Class:
Class H (180℃)
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Product Description
With a step angle of 1.8 degrees and a 2-phase design, this stepper motor provides precise and accurate positioning in a small package - measuring just 42mm x 42mm x 48mm.

With a high temperature rating, it can withstand environments that would cause other motors to fail. It has a holding torque of 0.59N.m and a current rating of 2.8A. It is CE and ROHS certified, ensuring that it meets the highest standards of quality and safety.

Use it in applications such as 3D printing, CNC machines, and robotics.



Features:

  • High torque and high precision

  • For high-tech industry and electronic industry equipment

  • Available in single or double shaft versions

  • Provide "multiple international certifications"

  • Established in China for 12 years and has served more than 800 customers.

Appearance

42x42x48mm 1.8 Degree High Temp Stepper Motor 0.59N.M 2.8A CE ROHS 0

Dimensions

42x42x48mm 1.8 Degree High Temp Stepper Motor 0.59N.M 2.8A CE ROHS 1

Motor Specifications



Step Angel

1.8 °

Fram Size

42 mm

Number of Phase

2 Phase

Rated Current

2.8 A

Holding Torque

590 mN.m

Resistance

1.4 ohm

Inductance

3.0 mH

Rotor Inertia

82 g-cm²

Motor weight

0.42 kg

Number of leads

4

Insulation class

Class H (180℃)

Operating Specifications

Step Angle: 1.8°

Maximum  Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min







Torque Curves













Submodels

Model Holding Torque Step Angle Motor Length Type of Shaft Rated Current
42SHD4950 0.13N.m 1.8° 20mm D Shaft-20mm 1.0A
42SHD4003 0.26N.m 1.8° 34mm D Shaft-20mm 0.4A
42SHD0261 0.45N.m 1.8° 40mm D Shaft-20mm 1.68A
42SHD4425 0.59N.m 1.8° 48mm D Shaft-24mm 2.0A
42SHD4813 0.8N.m 1.8° 60mm D Shaft-24mm 2.1A





Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:

Encoder

Brake

Gearbox

Shaft
42x42x48mm 1.8 Degree High Temp Stepper Motor 0.59N.M 2.8A CE ROHS 2 42x42x48mm 1.8 Degree High Temp Stepper Motor 0.59N.M 2.8A CE ROHS 3 42x42x48mm 1.8 Degree High Temp Stepper Motor 0.59N.M 2.8A CE ROHS 4 42x42x48mm 1.8 Degree High Temp Stepper Motor 0.59N.M 2.8A CE ROHS 5



Please click the "Get a quote" button below to tell us your requirements.
