120mN.M 1.5A NEMA 11 Stepper Motor 28x28x45mm Casun Stepping Motor For Robot

120mN.M 1.5A NEMA 11 Stepper Motor 28x28x45mm Casun Stepping Motor For Robot

Brand Name:	Casun
Model Number:	28SHD0405-10B
MOQ:	1PC
Price:	$6.89-$14
Payment Terms:	D/A, T/T, L/C, D/P
Supply Ability:	40000+PCS+Month

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

CE,ROHS,ISO

Step Angel:

1.8°

Holding Torque:

120mN.m

Current:

1.5A

Motor Length:

45mm

Shaft:

Milling Flat Shaft 10mm Length

Customized:

The Motor Can Be Designed &manufactured With Customized Request.

Packaging Details:

Carton:36x29x14cm

Highlight:

1.5A NEMA 11 Stepper Motor

NEMA 11 Stepper Motor For Robot

Product Description

120mN.M 1.5A NEMA 11 Stepper Motor 28x28x45mm Casun Stepping Motor For Robot

Black color NEMA 11 stepper motor with 120mN.m torque, 1.5A current rating, and compact 28x28x45mm dimensions. Ideal for robotic applications where space is limited.

The 28mm hybrid stepper motors are designed for tiny spaces and light equipment applications, offering precise position control with high precision and resolution.

Key Features

Available in unipolar or bipolar versions
Hybrid stepper construction
Research and development expertise in manufacturing
Specific models for different application requirements
Customizations available upon request

Motor Specifications

Step Angle	1.8°
Frame Size	28 mm
Number of Phase	2 Phase
Rated Current	1.5 A
Holding Torque	120 mN.m
Resistance	2.7 ohm
Inductance	1.9 mH
Rotor Inertia	9 g-cm²
Motor Weight	0.16 kg
Number of Leads	4
Connection	Bipolar

Appearance

Dimensions

Customization Available

If our standard motor cannot meet your requirements, we can customize the motor according to your specific needs. Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, and more.

Frequently Asked Questions

Who are we?

We are based in Guangdong, China, established in 2011. We serve domestic and international markets including Western Europe, North America, and Eastern Asia with 51-100 employees in our office.

How can we guarantee quality?

We provide pre-production samples before mass production and conduct final inspection before shipment to ensure quality standards.

What can you buy from us?

We specialize in stepper motors and BLDC motors.

Why should you buy from us?

We have over 11 years of specialized experience in producing and selling stepper motors.

What services can we provide?

Accepted delivery terms: FOB, CFR, CIF, EXW, Express Delivery. Accepted payment methods: T/T, L/C, D/P D/A, PayPal. Languages spoken: English, Chinese, Japanese.

Available Options

Encoder

Brake

Gearbox

Connector
