Bipolar Connection Micro Stepping Motor 0.6A 32mN.M Nema 8 Stepper Motor For Beauty Machine

Bipolar Connection Micro Stepping Motor 0.6A 32mN.M Nema 8 Stepper Motor For Beauty Machine

Brand Name:	CASUN
Model Number:	20SHD0250-20
MOQ:	1pcs-10pcs
Price:	US $6.94 - 11.00/ Piece
Payment Terms:	L/C, D/A, T/T
Supply Ability:	100000pcs / month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE,ROHS,ISO

Connector Type:

4-pin

Current:

0.6A

Detent Torque:

0.002Nm

Holding Torque:

0.032Nm

Inductance:

3mH

Length:

38mm

Name:

NEMA 8 Stepper Motor

Resistance:

9Ω

Rotor Inertia:

0.38g·cm²

Shaft Diameter:

5mm

Shaft Length:

20mm

Step Angle:

1.8°

Voltage:

5.4V

Customized:

The Motor Can Be Designed &manufactured With Customized Request.

Packaging Details:

Carton:38x29xc14m

Highlight:

Bipolar Connection Micro Stepping Motor

Micro Stepping Motor 0.6A

Nema 8 Stepper Motor

Product Description

Bipolar Connection Micro Stepping Motor 0.6A 32mN.M Nema 8 Stepper Motor

Compact Nema 8 stepper motor designed for beauty machines and video conference equipment with precise micro stepping capabilities.

Product Overview

Hot Sale Micro Stepping Motor 0.6A 32mN.M Nema 8 Stepper Motor specifically engineered for beauty machines and video conference equipment. This compact motor delivers reliable performance in space-constrained applications.

Key Applications

Beauty machines
Video conference equipment
Precision positioning systems

Product Appearance

Dimensions

Motor Specifications

Step Angle	1.8°
Frame Size	20 mm
Number of Phase	2 Phase
Rated Current	0.6 A
Holding Torque	32 mN.m
Resistance	9 ohm
Inductance	3 mH
Rotor Inertia	3.8 g-cm²
Motor Weight	0.08 kg
Number of Leads	4
Connection	Bipolar

Torque Curves

Detailed torque performance curves available upon request for engineering analysis and system integration.

Customization Options

If our standard motor cannot meet your requirements, we can customize the motor according to your specific needs.

Customized content includes but is not limited to:

Special shafts
Custom winding parameters
Modified installation dimensions
Lead wires with special requirements
Connectors and interface options

Available Options

Encoder
Brake
Gearbox
Connector
