0.6 A Nema 11 Micro Stepper Motor Small Size For Robot Ce Certifications

0.6 A Nema 11 Micro Stepper Motor Small Size For Robot Ce Certifications

Brand Name:	CASUN
Model Number:	20SHD0301-10
MOQ:	1pcs-10pcs
Price:	US $7.94 - 14.00/ Piece
Payment Terms:	L/C, D/A, T/T
Supply Ability:	100000pcs / month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE,ROHS,ISO

Connector Type:

4-pin

Current:

0.6A

Holding Torque:

22mN.m

Inductance:

2mH

Length:

27.5mm

Name:

NEMA 8 Stepper Motor

Resistance:

7.1Ω

Shaft Diameter:

4mm

Shaft Length:

10mm

Step Angle:

1.8°

Voltage:

4.26V

Customized:

The Motor Can Be Designed &manufactured With Customized Request.

Packaging Details:

Carton:38x29xc14m

Highlight:

Nema 11 Micro Stepper Motor

0.6A Micro Stepper Motor

Product Description

0.6 A Nema 11 Micro Stepper Motor Small Size For Robot Ce Certifications

0.6 A Nema 11 Micro Stepper Motor Small Size High Quality Stepping Motor For Robot With Ce Certifications. Micro 5.4V 2 Phase 0.6A Bipolar Nema 8 Stepper Motor for Robot 20*20*27.5mm.

Appearance

Dimensions

Motor Specifications

Step Angle	1.8°
Frame Size	20 mm
Number of Phase	2 Phase
Rated Current	0.6 A
Holding Torque	22 mN.m
Resistance	7.1 ohm
Inductance	2 mH
Rotor Inertia	2 g-cm²
Motor Weight	0.06 kg
Number of Leads	4
Connection	Bipolar

Torque Curves

Torque curve data available upon request.

Download

Technical documentation and specifications available for download.

Customization Available

If our standard motor cannot meet your needs, we can customize the motor according to your requirements. Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Frequently Asked Questions

Who are we? We are based in Guangdong, China, established in 2011, with 51-100 employees. Our primary markets include Domestic Market (63%), Western Europe (12%), North America (9%), and Eastern Asia (8%).
How can we guarantee quality? Always provide pre-production samples before mass production and conduct final inspection before shipment.
What can you buy from us? Stepper Motor, BLDC Motor
Why should you buy from us? We specialize in producing and selling stepper motors for more than 11 years.
What services can we provide? Accepted Delivery Terms: FOB, CFR, CIF, EXW, Express Delivery. Accepted Payment Currency: USD, CNY. Accepted Payment Type: T/T, L/C, D/P D/A, PayPal. Languages: English, Chinese, Japanese.

Available Options

Encoder

Brake

Gearbox

Connector
