202038mm 5.4V Nema 8 Stepper Motor For Scanner Device With CE ROHS

202038mm 5.4V Nema 8 Stepper Motor For Scanner Device With CE ROHS

Brand Name:	CASUN
Model Number:	20SHD0250-20
MOQ:	1pcs-10pcs
Price:	US $6.94 - 11.00/ Piece
Payment Terms:	L/C, D/A, T/T
Supply Ability:	100000pcs / month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE,ROHS,ISO

Connector Type:

4 Wiring

Current:

0.6A

Holding Torque:

32mN.m

Inductance:

3mH

Length:

38mm

Name:

NEMA 8 Stepper Motor

Resistance:

9Ω

Shaft Diameter:

4mm

Shaft Length:

20mm

Step Angle:

1.8°

Voltage:

5.4V

Customized:

The Motor Can Be Designed &manufactured With Customized Request.

Packaging Details:

Carton:38x29xc14m

Highlight:

5.4V Nema 8 Stepper Motor

Scanner Device Nema 8 Stepper Motor

Product Description

20×20×38mm 5.4V Nema 8 Stepper Motor for Scanner Device

High-precision Nema 8 stepper motor specifically designed for scanner devices and robotics applications. Certified with CE and ROHS compliance for quality assurance.

Product Appearance

Motor Dimensions

Technical Specifications

Parameter	Specification
Step Angle	1.8°
Frame Size	20 mm
Number of Phase	2 Phase
Rated Current	0.6 A
Holding Torque	32 mN.m
Resistance	9 ohm
Inductance	3 mH
Rotor Inertia	3.8 g-cm²
Motor Weight	0.08 kg
Number of Leads	4
Connection	Leading

Available Options

Encoder

Brake

Gearbox

Connector

Customization Services

If our standard motor cannot meet your requirements, we offer comprehensive customization services including:

Special shaft designs
Custom winding parameters
Modified installation dimensions
Special requirement lead wires
Custom connectors

Quality Assurance

Pre-production samples provided before mass production
Final inspection conducted before shipment
Over 11 years of specialized stepper motor manufacturing experience
