0.5Amp Nema 11 Ball Screw Rod Stepper Motor 32mN.M Linear Stepper Motor

0.5Amp Nema 11 Ball Screw Rod Stepper Motor 32mN.M Linear Stepper Motor

Brand Name:	Casun
Model Number:	28SHD4050-49GP
MOQ:	1PC
Price:	$8.98-$12.98
Payment Terms:	D/A, T/T, L/C, D/P
Supply Ability:	40000+PCS+Month

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

CE,ROHS,ISO

Color:

Black

Current:

0.5Amp

Weight:

0.23kg

Customized:

The Motor Can Be Designed &manufactured With Customized Request.

Packaging Details:

Carton:38x29xc14m

Highlight:

32mN.M Ball Screw Rod Stepper Motor

0.5Amp Ball Screw Rod Stepper Motor

Product Description

0.5Amp Nema 11 Ball Screw Rod Stepper Motor 32mN.M Linear Stepper Motor

Nema11 Ball Screw Rod Stepper Motor 32mN.M Linear Stepper Motor

A ball screw stepper motor is a type of stepper motor that incorporates a ball screw mechanism for linear motion. It combines the rotational motion of a stepper motor with the linear motion capabilities of a ball screw to achieve precise and controlled linear movements.

NEMA 11 is a standard motor frame size defined by the National Electrical Manufacturers Association (NEMA). The NEMA 11 standard specifies the physical dimensions and mounting arrangements of the motor, allowing for interchangeability between different manufacturers.

Features

Bipolar or unipolar versions available
Hybrid stepper construction
Available in single or double shaft versions
CE and RoHS approved
Customizations on request

Dimensions

Motor Specifications

Specification	Value
Step Angle	1.8°
Frame Size	28mm
Number of Phase	2 Phase
Rated Current	0.5Amp
Holding Torque	32mN.m
Resistance	0ohm
Inductance	mH
Rotor Inertia	g-cm²
Motor Weight	0.26kg
Lead Screw	49mm
Connection	Bipolar

Operating Specifications

Step Angle	1.8°
Maximum Temperature	80°C maximum
Ambient Temperature	-20°C to 50°C
Storage Temperature	-20°C to 100°C
Humidity Range	85% or less, non-condensing
Magnet Wire Insulation	Class B 130 deg C
Insulation Resistance	100M Ohm at 500 VDC
Dielectric Strength	500 VDC for 1 min
Shaft Radial Play	0.02Max. (450g-load)
Shaft Axial Play	0.08Max. (450g-load)
Max. Radial Force	28N (20mm from the flange)
Max. Axial Force	10N

Submodels

Model	Holding Torque	Step Angle	Motor Length	Type of Shaft	Rated Current
42SHD4950	0.13N.m	1.8°	20mm	D Shaft-20mm	1.0A
42SHD4003	0.26N.m	1.8°	34mm	D Shaft-20mm	0.4A
42SHD0261	0.45N.m	1.8°	40mm	D Shaft-20mm	1.68A
42SHD4425	0.59N.m	1.8°	48mm	D Shaft-24mm	2.0A
42SHD4813	0.8N.m	1.8°	60mm	D Shaft-24mm	2.1A

Customization Options

If our standard motor cannot meet your needs, we can customize the motor according to your requirements.

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Available Options:

Encoder

Brake

Gearbox

Shaft

Please click the "Get a quote" button below to tell us your requirements.

Get a Quote
