14HS10-0404S Nema 14 Stepper Motor 0.4A Dc Motor For Robot

name

14HS10-0404S Nema 14 Stepper Motor 0.4A Dc Motor For Robot

Brand Name: Casun
Model Number: P35SHD4007-21B
MOQ: 1PC
Price: $4-$9
Payment Terms: D/A, T/T, L/C, D/P
Supply Ability: 40000+PCS+Month
Detail Information
Product Description
Detail Information
Place of Origin:
CHINA
Certification:
CE,ROSH,ISO
Step Angel:
1.8°
Holding Torque:
140mN.m
Current:
0.4A
Motor Length:
26mm
Shaft:
20mm Length
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Packaging Details:
Carton:36x29x14cm
Highlight:

14HS10-0404S Nema 14 Stepper Motor

,

0.4A Nema 14 Stepper Motor

Product Description
14HS10-0404S Nema 14 Stepper Motor 0.4A DC Motor For Robot
Casun Mini Step Motor Nema14 35x35x26mm 140mN.M Stepper Motor designed for medical machines and robotic applications requiring precise and controlled movements.
Motor Specifications
Step Angle 1.8°
Frame Size 35 mm
Number of Phase 2 Phase
Rated Current 0.4A
Holding Torque 140 mN.m
Resistance 30 ohm
Inductance 30 mH
Rotor Inertia 35 g-cm²
Motor Weight 12 kg
Number of Leads 4
Connection Bipolar
Appearance & Dimensions
14HS10-0404S Nema 14 Stepper Motor 0.4A Dc Motor For Robot 0 14HS10-0404S Nema 14 Stepper Motor 0.4A Dc Motor For Robot 1
Product Overview
  • Motor Type: 2-phase stepper motor
  • Torque: 140mN.m (millinewton-meter)
  • Current: 0.4A (Amperes)
  • Dimensions: 35x35x26mm (width x depth x height)

This stepper motor is designed for medical machines and applications requiring precise and controlled movements. Stepper motors are commonly used in various industries including robotics, automation, 3D printers, and CNC machines.

Custom Motor Solutions

If our standard motor cannot meet your needs, we can customize the motor according to your requirements.

Customized content includes but is not limited to:

  • Special shafts
  • Winding parameters
  • Installation dimensions
  • Lead wires with special requirements
  • Connectors
Available Options
Encoder
Brake
Gearbox
Connector
Get a Quote
