GUANGZHOU FUDE ELECTRONIC TECHNOLOGY CO.,LTD Company Profile
products
Home > products > Non Captive Stepper Motor > DC Linear NEMA 23 Hollow Shaft Stepper Motor 100mm Body 4.5A Nc Machine
DC Linear NEMA 23 Hollow Shaft Stepper Motor 100mm Body 4.5A Nc Machine
DC Linear NEMA 23 Hollow Shaft Stepper Motor 100mm Body 4.5A Nc Machine
DC Linear NEMA 23 Hollow Shaft Stepper Motor 100mm Body 4.5A Nc Machine
DC Linear NEMA 23 Hollow Shaft Stepper Motor 100mm Body 4.5A Nc Machine
DC Linear NEMA 23 Hollow Shaft Stepper Motor 100mm Body 4.5A Nc Machine
DC Linear NEMA 23 Hollow Shaft Stepper Motor 100mm Body 4.5A Nc Machine
DC Linear NEMA 23 Hollow Shaft Stepper Motor 100mm Body 4.5A Nc Machine

DC Linear NEMA 23 Hollow Shaft Stepper Motor 100mm Body 4.5A Nc Machine

Product Details

Place of Origin: CHINA

Brand Name: Casun

Certification: CE,ROHS,ISO

Model Number: 57SHD4935-KH

Payment & Shipping Terms

Minimum Order Quantity: 1PC

Price: $3.14-$5

Packaging Details: Carton:36x29x14cm

Delivery Time: 7-15 days

Payment Terms: D/A, T/T, L/C, D/P

Supply Ability: 40000+PCS+Month

Get Best Price

Product Details

Product Description
Product Details
Highlight:

NEMA 23 Hollow Shaft Stepper Motor

,

DC Linear Hollow Shaft Stepper Motor

Step Angel:
1.8°
Holding Torque:
3000mN.m
Current:
4.5A
Motor Length:
100mm
Shaft:
None
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Step Angel:
1.8°
Holding Torque:
3000mN.m
Current:
4.5A
Motor Length:
100mm
Shaft:
None
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Product Description

DC Linear NEMA 23 Hollow Shaft Stepper Motor 100mm Body 4.5A Nc Machine

The 57mm Hybrid Stepper Motor Series comes in a range of sizes and provides strong holding torque.

Widely used in fields such as automation equipment, robotics technology, and CNC machine tools.



Features:

  • Both high torque and accuracy

  • For electronic industrial equipment and high-tech industry equipment

  • Within 48 hours, one of our engineers will contact you with the best option

  • Ten-year warranty and confidence in purchasing

  • Each model of stepper motor can be suitable for different scenarios







Motor Specifications



Step Angel

1.8 °

Fram Size

57 mm

Number of Phase

2 Phase

Rated Current

4.5 A

Holding Torque

3000 mN.m

Resistance

1.3 ohm

Inductance

6.0 mH

Rotor Inertia

650 g-cm²

Motor weight

1 kg

Number of leads

4

Connection

Bipolar

Appearance

DC Linear NEMA 23 Hollow Shaft Stepper Motor 100mm Body 4.5A Nc Machine 0

Dimensions

DC Linear NEMA 23 Hollow Shaft Stepper Motor 100mm Body 4.5A Nc Machine 1


Operating Specifications

Step Angle: 1.8°

Maximum  Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min







Torque Curves













Submodels



Model Holding Torque Step Angle Length Type of Shaft Rated Current
57SHD4013-21B 0.6N.m 1.8° 41mm D Shaft-21mm 1.0A
57SHD4415-21B 1.1N.m 1.8° 54mm D Shaft-21mm 3.0A
57SHD4816-21B 2.0N.m 1.8° 76mm D Shaft-21mm 3.0A
57SHD4913-21B 2.5N.m 1.8° 83mm D Shaft-21mm 3.0A
57SHD4934-20B 3.0N.m 1.8° 100mm D Shaft-20mm 3.0A



Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:

Encoder

Brake

Gearbox

Shaft
DC Linear NEMA 23 Hollow Shaft Stepper Motor 100mm Body 4.5A Nc Machine 2 DC Linear NEMA 23 Hollow Shaft Stepper Motor 100mm Body 4.5A Nc Machine 3 DC Linear NEMA 23 Hollow Shaft Stepper Motor 100mm Body 4.5A Nc Machine 4 DC Linear NEMA 23 Hollow Shaft Stepper Motor 100mm Body 4.5A Nc Machine 5



Please click the "Get a quote" button below to tell us your requirements.
