Nema 24 Closed Loop Stepper Motor 4.1N.m 60*60*100mm With Permanent Magnet Brake

name

Nema 24 Closed Loop Stepper Motor 4.1N.m 60*60*100mm With Permanent Magnet Brake

Brand Name: Casun
Model Number: 60shd4701-24BH-HP60
MOQ: 1PC
Price: $26.46-$50.46
Payment Terms: D/A, T/T, L/C, D/P
Supply Ability: 40000+PCS+Month
Detail Information
Product Description
Detail Information
Place of Origin:
CHINA
Certification:
CE,ROHS,ISO
Step Angel:
1.8°
Holding Torque:
4.1N.m
Motor Length:
100mm
Shaft:
24mm Length
Number Of Phases:
2
Length:
100mm
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Packaging Details:
Carton:36x29x14cm
Highlight:

Nema 24 Closed Loop Stepper Motor

,

4.1N.m Closed Loop Stepper Motor

Product Description
Nema 24 Closed Loop Stepper Motor 4.1N.m 60×60×100mm With Permanent Magnet Brake
The 60mm brake stepper motor generates relatively low noise and vibration during operation, making the motor smoother and quieter during operation. Widely used in various industrial applications, such as automation equipment, robots, packaging machinery, etc.
Key Features
  • High torque and high precision
  • Personalized services and contract production available
  • Available in single or double shaft versions
  • Distributor opportunities available
  • Professional research and development manufacturing
Appearance
Nema 24 Closed Loop Stepper Motor 4.1N.m 60*60*100mm With Permanent Magnet Brake 0
Dimensions
Nema 24 Closed Loop Stepper Motor 4.1N.m 60*60*100mm With Permanent Magnet Brake 1
Motor Specifications
Step Angle 1.8°
Frame Size 60mm
Number of Phase 2 Phase
Rated Current 3.5 A
Holding Torque 4.1 N.m
Resistance 1.2 ohm
Inductance 3.9 mH
Rotor Inertia 1000 g-cm²
Motor Weight 1.5 kg
Number of Leads 4
Connection Bipolar
Operating Specifications
Step Angle 1.8°
Maximum Temperature 80°C maximum
Ambient Temperature -20°C to 50°C
Storage Temperature -20°C to 100°C
Humidity Range 85% or less, non-condensing
Magnet Wire Insulation Class B 130°C
Insulation Resistance 100M Ohm at 500 VDC
Dielectric Strength 500 VDC for 1 min
Submodels
Model Holding Torque Rated Current Resistance per phase Inductance per phase Detent torque Rotor inertia Lead wire Motor length
60SHD4201 650 mN.m 0.6 A 15 Ω 20 mH 50 mN.m 280 g.cm² 4 45 mm
60SHD4401 1500 mN.m 2.8 A 1 Ω 3.3 mH 70 mN.m 450 g.cm² 4 56 mm
60SHD4601 3200 mN.m 4.2 A 0.75 Ω 3.7 mH 120 mN.m 580 g.cm² 4 86 mm
60SHD6602 2500 mN.m 3 A 1.55 Ω 3.7 mH 120 mN.m 580 g.cm² 4 -
Customization Options
If our standard motor cannot meet your needs, we can customize the motor according to your requirements. Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.
Encoder
Nema 24 Closed Loop Stepper Motor 4.1N.m 60*60*100mm With Permanent Magnet Brake 2
Brake
Nema 24 Closed Loop Stepper Motor 4.1N.m 60*60*100mm With Permanent Magnet Brake 3
Gearbox
Nema 24 Closed Loop Stepper Motor 4.1N.m 60*60*100mm With Permanent Magnet Brake 4
Shaft
Nema 24 Closed Loop Stepper Motor 4.1N.m 60*60*100mm With Permanent Magnet Brake 5
