NEMA 11 Mini Stepper Motor 0.67A 95mN.m 44.5mm Body For Medical Equipment

name

NEMA 11 Mini Stepper Motor 0.67A 95mN.m 44.5mm Body For Medical Equipment

Brand Name: Casun
Model Number: 28SHD4401-20B1
MOQ: 1PC
Price: $5.94-$8.6
Payment Terms: D/A, T/T, L/C, D/P
Supply Ability: 40000+PCS+Month
Detail Information
Product Description
Detail Information
Place of Origin:
CHINA
Certification:
CE,ROSH,ISO
Step Angel:
1.8°
Holding Torque:
95mN.m
Current:
0.67A
Motor Length:
44mm
Certifications:
CE ISO ROHS
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Packaging Details:
Carton:36x29x14cm
Highlight:

44.5mm NEMA 11 Mini Stepper Motor

,

95mN.m NEMA 11 Mini Stepper Motor

,

0.67A NEMA 11 Mini Stepper Motor

Product Description

NEMA 11 stepper motors provide relatively high torque while maintaining a small volume

Suitable for various industries and applications, including medical equipment, laboratory instruments, small robots, precision positioning systems, etc.



Features:

  • Each model of stepper motor can be suitable for different scenarios

  • Needed dealers! !

  • Available in single or double shaft versions

  • Specialized in R&D and manufacturing

  • Our engineering team will reach out within 48 hours to deliver the optimal solution





Motor Specifications

Step Angel

1.8 °

Fram Size

28 mm

Number of Phase

2 Phase

Rated Current

0.67 A

Holding Torque

95 mN.m

Resistance

6.8 ohm

Inductance

5 mH

Rotor Inertia

9 g-cm²

Motor weight

0.12 kg

Number of leads

4

Connection

Bipolar





Appearance



NEMA 11 Mini Stepper Motor 0.67A 95mN.m 44.5mm Body For Medical Equipment 0

Dimensions

NEMA 11 Mini Stepper Motor 0.67A 95mN.m 44.5mm Body For Medical Equipment 1



Torque Curves



















Download







If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Connector

Please click the "Get  a quote" button below to tell us your requirements.
