products details

Created with Pixso. Home Created with Pixso. Products Created with Pixso.
Hybrid Stepper Motor
Created with Pixso.

High Accuracy 1.8 Degree 28*28*45mm Nema 11 Hybrid Stepper Motor 1.5A for ATM Machine

name

High Accuracy 1.8 Degree 28*28*45mm Nema 11 Hybrid Stepper Motor 1.5A for ATM Machine

Brand Name: Casun
Model Number: 28SHD0405-15B
MOQ: 1PC
Price: $6.89-$14
Payment Terms: D/A, T/T, L/C, D/P
Supply Ability: 40000+PCS+Month
Detail Information
Product Description
Detail Information
Place of Origin:
CHINA
Certification:
CE,ROHS,ISO
Step Angel:
1.8°
Holding Torque:
120mN.m
Current:
1.5A
Motor Length:
45mm
Shaft:
Milling Flat Shaft 10mm Length
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Packaging Details:
Carton:36x29x14cm
Highlight:

1.5A Nema 11 Hybrid Stepper Motor

,

28*28*45mm Nema 11 Hybrid Stepper Motor

Product Description

It has a wide range of application advantages in the fields of automation control and precision positioning.



3D printers, small robots, medical equipment, automatic testing equipment, etc.





Features:

  • Versions in unipolar or bipolar are offered

  • Hybrid stepper building

  • Production with knowledge of research and development

  • With 12 years of establishment in China and a clientele exceeding 800

  • Offering a ten-year warranty for confident purchasing





Motor Specifications

Step Angel

1.8 °

Fram Size

28 mm

Number of Phase

2 Phase

Rated Current

1.5 A

Holding Torque

120 mN.m

Resistance

2.7 ohm

Inductance

1.9 mH

Rotor Inertia

9 g-cm²

Motor weight

0.16 kg

Number of leads

4

Connection

Bipolar





Dimensions

High Accuracy 1.8 Degree 28*28*45mm Nema 11 Hybrid Stepper Motor 1.5A for ATM Machine 0





Torque Curves



















Download







If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

FAQ

1. who are we?

We are based in Guangdong, China, start from 2011,sell to Domestic Market(63.00%),Western Europe(12.00%),North America(9.00%),Eastern Asia(8.00%),Northern Europe(2.00%),Eastern Europe(00.00%),Southeast Asia(00.00%),Oceania(00.00%),Mid East(00.00%),Southern Europe(00.00%),South Asia(00.00%). There are total about 51-100 people in our office.



2. how can we guarantee quality?

Always a pre-production sample before mass production;

Always final Inspection before shipment;



3.what can you buy from us?

Stepper Motor,BLDC Motor



4. why should you buy from us not from other suppliers?

We are specialized in producing and selling stepper motors for more than 11 years.



5. what services can we provide?

Accepted Delivery Terms: FOB,CFR,CIF,EXW,Express Delivery；

Accepted Payment Currency:USD,CNY;

Accepted Payment Type: T/T,L/C,D/P D/A,,PayPal;

Language Spoken:English,Chinese,Japanese

Options:
Encoder | Brake | Gearbox | Connector

Please click the "Get  a quote" button below to tell us your requirements.











Tags:

2 Phase Bipolar Stepper Motor

Nema 6 Bipolar Stepper Motor

1.5A Nema 11 Hybrid Stepper Motor
