Home > products > Hybrid Stepper Motor > Nema 23 Bipolar 1.8deg 1.2Nm (170oz.in) 57x57x54mm 4 Wires Stepper Motor For XYZ Axis CNC
Nema 23 Bipolar 1.8deg 1.2Nm (170oz.in) 57x57x54mm 4 Wires Stepper Motor For XYZ Axis CNC
Nema 23 Bipolar 1.8deg 1.2Nm (170oz.in) 57x57x54mm 4 Wires Stepper Motor For XYZ Axis CNC
Nema 23 Bipolar 1.8deg 1.2Nm (170oz.in) 57x57x54mm 4 Wires Stepper Motor For XYZ Axis CNC
Nema 23 Bipolar 1.8deg 1.2Nm (170oz.in) 57x57x54mm 4 Wires Stepper Motor For XYZ Axis CNC
Nema 23 Bipolar 1.8deg 1.2Nm (170oz.in) 57x57x54mm 4 Wires Stepper Motor For XYZ Axis CNC
Nema 23 Bipolar 1.8deg 1.2Nm (170oz.in) 57x57x54mm 4 Wires Stepper Motor For XYZ Axis CNC

Nema 23 Bipolar 1.8deg 1.2Nm (170oz.in) 57x57x54mm 4 Wires Stepper Motor For XYZ Axis CNC

Product Details

Place of Origin: CHINA

Brand Name: Casun

Certification: CE,ROHS,ISO

Model Number: 57SHD4407-28H

Payment & Shipping Terms

Minimum Order Quantity: 1PC

Price: $3.14-$5

Packaging Details: Carton:36x29x14cm

Delivery Time: 7-15 days

Payment Terms: D/A, T/T, L/C, D/P

Supply Ability: 40000+PCS+Month

Get Best Price

Product Details

Product Description
Product Details
Highlight:

57x57x54mm Nema 23 Bipolar Stepper Motor

,

1.2Nm Nema 23 Bipolar Stepper Motor

,

1.8deg Nema 23 Bipolar Stepper Motor

Step Angel:
1.8°
Holding Torque:
1.2N.m
Current:
2.0A
Motor Length:
54mm
Shaft:
Milling Flat Shaft 28mm Length
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Step Angel:
1.8°
Holding Torque:
1.2N.m
Current:
2.0A
Motor Length:
54mm
Shaft:
Milling Flat Shaft 28mm Length
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Product Description

The stepper motor does not experience speed fluctuations at low speeds, ensuring the stability and reliability of the system.

In the field of industrial automation, stepper motors can be used for driving and controlling various equipment.



Features:

  • High torque and high precision

  • Professional drivetrain solution specialist

  • Ten-year warranty and purchase with confidence

  • Provide “multiple international certifications” for high-tech industry and electronic industry equipment

  • Provide bespoke services

Appearance

Nema 23 Bipolar 1.8deg 1.2Nm (170oz.in) 57x57x54mm 4 Wires Stepper Motor For XYZ Axis CNC 0

Dimensions

Nema 23 Bipolar 1.8deg 1.2Nm (170oz.in) 57x57x54mm 4 Wires Stepper Motor For XYZ Axis CNC 1

Motor Specifications



Step Angel

1.8 °

Fram Size

57 mm

Number of Phase

2 Phase

Rated Current

2.0 A

Holding Torque

1.2 N.m

Resistance

1.4 ohm

Inductance

5 mH

Rotor Inertia

260 g-cm²

Motor weight

0.6 kg

Number of leads

4

Connection

Bipolar

Operating Specifications

Step Angle: 1.8°

Maximum  Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min







Torque Curves













Submodels



Model Holding Torque Step Angle Length Type of Shaft Rated Current
57SHD4013-21B 0.6N.m 1.8° 41mm D Shaft-21mm 1.0A
57SHD4415-21B 1.1N.m 1.8° 54mm D Shaft-21mm 3.0A
57SHD4816-21B 2.0N.m 1.8° 76mm D Shaft-21mm 3.0A
57SHD4913-21B 2.5N.m 1.8° 83mm D Shaft-21mm 3.0A
57SHD4934-20B 3.0N.m 1.8° 100mm D Shaft-20mm 3.0A



Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:

Encoder

Brake

Gearbox

Shaft
Nema 23 Bipolar 1.8deg 1.2Nm (170oz.in) 57x57x54mm 4 Wires Stepper Motor For XYZ Axis CNC 2 Nema 23 Bipolar 1.8deg 1.2Nm (170oz.in) 57x57x54mm 4 Wires Stepper Motor For XYZ Axis CNC 3 Nema 23 Bipolar 1.8deg 1.2Nm (170oz.in) 57x57x54mm 4 Wires Stepper Motor For XYZ Axis CNC 4 Nema 23 Bipolar 1.8deg 1.2Nm (170oz.in) 57x57x54mm 4 Wires Stepper Motor For XYZ Axis CNC 5



Please click the "Get a quote" button below to tell us your requirements.
