Home > products > Lead Screw Stepper Motor > NEMA 17 Captive Stepper Motor Ultrathin 20mm Body 1.0A 0.13N.m For Precise Instrument
NEMA 17 Captive Stepper Motor Ultrathin 20mm Body 1.0A 0.13N.m For Precise Instrument
NEMA 17 Captive Stepper Motor Ultrathin 20mm Body 1.0A 0.13N.m For Precise Instrument
NEMA 17 Captive Stepper Motor Ultrathin 20mm Body 1.0A 0.13N.m For Precise Instrument
NEMA 17 Captive Stepper Motor Ultrathin 20mm Body 1.0A 0.13N.m For Precise Instrument
NEMA 17 Captive Stepper Motor Ultrathin 20mm Body 1.0A 0.13N.m For Precise Instrument
NEMA 17 Captive Stepper Motor Ultrathin 20mm Body 1.0A 0.13N.m For Precise Instrument
NEMA 17 Captive Stepper Motor Ultrathin 20mm Body 1.0A 0.13N.m For Precise Instrument

NEMA 17 Captive Stepper Motor Ultrathin 20mm Body 1.0A 0.13N.m For Precise Instrument

Product Details

Place of Origin: CHINA

Brand Name: Casun

Certification: CE,ROSH,ISO

Model Number: 42SHD4950-135NT1

Payment & Shipping Terms

Minimum Order Quantity: 1PC

Price: $9.68-$14

Packaging Details: Carton:38x29xc14m

Delivery Time: 7-15 days

Payment Terms: D/A, T/T, L/C, D/P

Supply Ability: 40000+PCS+Month

Get Best Price

Product Details

Product Description
Product Details
Highlight:

0.13N.m NEMA 17 Captive Stepper Motor

,

1.0A NEMA 17 Captive Stepper Motor

Body:
20mm
Weight:
0.14kg
Shaft Diameter:
Tr5*2
Rate Current:
1.0A
Phase:
2
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Body:
20mm
Weight:
0.14kg
Shaft Diameter:
Tr5*2
Rate Current:
1.0A
Phase:
2
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Product Description

It can directly generate linear motion without the need for additional conversion devices, simplifying the mechanical structure.

By changing the pulse frequency, the movement speed of the screw can be easily adjusted.

Features:

  • Bipolar or unipolar versions available

  • Our engineering team guarantees contact within 48 hours to present the optimal solution

  • Recruiting enthusiastic distributors!

  • Every stepper motor model is adaptable to various applications

  • We specialize in professional drivetrain solutions·

Dimensions

NEMA 17 Captive Stepper Motor Ultrathin 20mm Body 1.0A 0.13N.m For Precise Instrument 0





Motor Specifications

Step Angel



1.8 °

Fram Size



42 mm

Number of Phase



2 Phase

Rated Current



1.0A

Holding Torque



130 mN.m

Resistance



3.5 hm

Inductance



4.5 mH

Rotor Inertia



15 g-cm²

Motor weight



0.14 kg

Lead Screw



Tr5X2

Connection



Bipolar



Operating Specifications





Step Angle: 1.8°

Maximum  Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min

Shaft Radial Play:0.02Max. (450g-load)

Shaft Axial Play:0.08Max. (450g-load)

Max. radial force:28N (20mm from the flange)

Max. axial force):10N







Torque Curves





Submodels



Model Holding Torque Step Angle Motor Length Type of Shaft Rated Current
42SHD4950 0.13N.m 1.8° 20mm D Shaft-20mm 1.0A
42SHD4003 0.26N.m 1.8° 34mm D Shaft-20mm 0.4A
42SHD0261 0.45N.m 1.8° 40mm D Shaft-20mm 1.68A
42SHD4425 0.59N.m 1.8° 48mm D Shaft-24mm 2.0A
42SHD4813 0.8N.m 1.8° 60mm D Shaft-24mm 2.1A





Body Length Diameter of Screw Pitch Length of Screw
20 mm

34 mm

40 mm

48 mm

60 mm
 		 5 2 20-1000 mm
8
6.35 1.27
3.175
6.35
6.5 3
6.35
8 1
2
4
8
12



Download







If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
            Encoder          |               Brake           |              Gearbox            |           Shaft

NEMA 17 Captive Stepper Motor Ultrathin 20mm Body 1.0A 0.13N.m For Precise Instrument 1 NEMA 17 Captive Stepper Motor Ultrathin 20mm Body 1.0A 0.13N.m For Precise Instrument 2 NEMA 17 Captive Stepper Motor Ultrathin 20mm Body 1.0A 0.13N.m For Precise Instrument 3 NEMA 17 Captive Stepper Motor Ultrathin 20mm Body 1.0A 0.13N.m For Precise Instrument 4





Please click the "Get  a quote" button below to tell us your requirements.
