100mN.m Hybrid Stepper Motor 1.5A 3.83V Stepping Motor For CNC ATM Robot Arm

name

100mN.m Hybrid Stepper Motor 1.5A 3.83V Stepping Motor For CNC ATM Robot Arm

Brand Name: Casun
Model Number: 28SHD0405-15B
MOQ: 1PC
Price: $23.94-$28.34
Payment Terms: D/A, T/T, L/C, D/P
Supply Ability: 40000+PCS+Month
Detail Information
Product Description
Detail Information
Place of Origin:
CHINA
Certification:
CE,ROHS,ISO
Step Angle:
1.8°
Rated Voltage:
3.83V
Detent Torque:
5mN.m
Rated Current:
1.5A
Holding Torque:
100mN.m
Mass:
0.16kg
Packaging Details:
Carton:38x29xc14m
Highlight:

1.5A Hybrid Stepper Motor

,

CNC Hybrid Stepper Motor

,

3.83V Hybrid Stepper Motor

Product Description

Nema11 28X28MM Hybrid Stepper Motor

The 28mm Hybrid Stepper Motor Series offers powerful holding torque in a variety of sizes.

Use with a microstepping driver to reduce vibration and achieve higher step resolution.

Choose a baseline version or request your own customized configuration.



Features:

  • Bipolar or unipolar versions available

  • Hybrid stepper construction

  • Available in single or double shaft versions

  • CE and RoHS approved

  • Customizations on request

Dimensions

100mN.m Hybrid Stepper Motor 1.5A 3.83V Stepping Motor For CNC ATM Robot Arm 0







Motor Specifications



Step Angel



1.8 °

Rated voltage



3.83 V DC

Number of Phase



2 Phase

Rated Current



1.5Amp

Holding Torque



100mN.m

Detent torque



5mN.m

Phase resistance



2.7ohm±10%(At 20℃)

Phase inductance



1.9mH±20%(1kHz  rms)

Rotor inertia



9g.cm

Motor weight



0.16kg
Insulation resistance

100MΩmin.(500V DC)

Insulation class



Class B











Download







If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
            Encoder          |               Brake           |              Gearbox            |           Shaft

100mN.m Hybrid Stepper Motor 1.5A 3.83V Stepping Motor For CNC ATM Robot Arm 1 100mN.m Hybrid Stepper Motor 1.5A 3.83V Stepping Motor For CNC ATM Robot Arm 2 100mN.m Hybrid Stepper Motor 1.5A 3.83V Stepping Motor For CNC ATM Robot Arm 3 100mN.m Hybrid Stepper Motor 1.5A 3.83V Stepping Motor For CNC ATM Robot Arm 4





Please click the "Get  a quote" button below to tell us your requirements.
