NEMA 8 Non Captive DC Stepper Motor 38mm Body Tr5×2 For Beauty Equipment

NEMA 8 Non Captive DC Stepper Motor 38mm Body Tr5×2 For Beauty Equipment

Brand Name:	Casun
Model Number:	20SHD0250-150NT
MOQ:	1PC
Price:	$13-$13.5
Payment Terms:	D/A, T/T, L/C, D/P
Supply Ability:	40000+PCS+Month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE,ROHS,ISO

Color:

Black

Current:

0.6Amp

Holding Torque:

32mN.m

Detent Torque:

2mN.m

Lead Screw:

Tr5×2

Customized:

The Motor Can Be Designed &manufactured With Customized Request.

Packaging Details:

Carton:38x29xc14m

Highlight:

38mm Body Non Captive Stepper Motor

DC Non Captive Stepper Motor

Beauty Equipment Non Captive Stepper Motor

Product Description

During the operation of the stepper motor, the meshing between the screw and the lead screw ensures smooth linear motion and minimal vibration.

Due to its simple structure, the through screw stepper motor is easy to integrate with other equipment and systems

Features:

Contract-based manufacturing services are welcome
Ten-year warranty, buy with confidence
Our engineers will contact you within 48 hours to offer the most suitable solution
CE and RoHS approved
Every stepper motor model is adaptable to various applications

Dimensions

Motor Specifications

Step Angel	1.8 °
Fram Size	20 mm
Number of Phase	2 Phase
Rated Current	0.6Amp
Holding Torque	32mN.m
Resistance	9.0ohm
Inductance	3.0mH
Rotor Inertia	3.8g-cm²
Motor weight	0.08kg
Lead Screw	Tr5X2
Connection	Bipolar

Operating Specifications

Step Angle: 1.8°

Maximum Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min

Shaft Radial Play:0.02Max. (450g-load)

Shaft Axial Play:0.08Max. (450g-load)

Max. radial force:28N (20mm from the flange)

Max. axial force):10N

Torque Curves

Submodels

Model	Holding Torque	Step Angle	Motor Length	Type of Shaft	Rated Current
42SHD4950	0.13N.m	1.8°	20mm	D Shaft-20mm	1.0A
42SHD4003	0.26N.m	1.8°	34mm	D Shaft-20mm	0.4A
42SHD0261	0.45N.m	1.8°	40mm	D Shaft-20mm	1.68A
42SHD4425	0.59N.m	1.8°	48mm	D Shaft-24mm	2.0A
42SHD4813	0.8N.m	1.8°	60mm	D Shaft-24mm	2.1A

Body Length	Diameter of Screw	Pitch	Length of Screw
20 mm 34 mm 40 mm 48 mm 60 mm	5	2	20-1000 mm
		8
	6.35	1.27
		3.175
		6.35
	6.5	3
		6.35
	8	1
		2
		4
		8
		12

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Shaft

NEMA 8 Non Captive DC Stepper Motor 38mm Body Tr5×2 For Beauty Equipment 1

Please click the "Get a quote" button below to tell us your requirements.
