Waterproof Stepper Motor
Created with Pixso.

Waterproof Grade IP65 Stepping Motor 1.0A 0.22N.m 42×42×42.6mm NEMA 17 With ISO CE

name

Waterproof Grade IP65 Stepping Motor 1.0A 0.22N.m 42×42×42.6mm NEMA 17 With ISO CE

Brand Name: Casun
Model Number: F42SHD40121-8BH
MOQ: 1PC
Price: $5.0-$6.2
Payment Terms: D/A, T/T, L/C, D/P
Supply Ability: 40000+PCS+Month
Detail Information
Product Description
Detail Information
Place of Origin:
CHINA
Certification:
CE,ROSH,ISO
Step Angel:
1.8°
Holding Torque:
220mN.m
Current:
1.0A
Motor Length:
42mm
Shaft:
Milling Flat Shaft 8mm Length
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Packaging Details:
Carton:36x29x14cm
Highlight:

0.22N.m Stepping Motor

,

Waterproof grade IP65 Stepping Motor

,

1.0A Stepping Motor

Product Description

Dual axis stepper motors can adapt to various applications, from simple linear motion to complex multi axis motion control.

The dual axis design can better achieve dual axis synchronous control and improve the positioning accuracy of the system.



Features:

  • Our engineers will contact you within two days to offer the most effective solution

  • Customized service offerings

  • Available in single or double shaft versions

  • Contract manufacturing is a service we offer

  • We specialize in providing professional drivetrain solutions





Motor Specifications

Step Angel

1.8 °

Fram Size

42 mm

Number of Phase

2 Phase

Rated Current

1.0 A

Holding Torque

220 mN.m

Resistance

3.6 ohm

Inductance

4.6 mH

Rotor Inertia

35 g-cm²

Motor weight

- kg

Number of leads

4

Connection

Bipolar

Appearance

Waterproof Grade IP65 Stepping Motor 1.0A 0.22N.m 42×42×42.6mm NEMA 17 With ISO CE 0

Dimensions

Waterproof Grade IP65 Stepping Motor 1.0A 0.22N.m 42×42×42.6mm NEMA 17 With ISO CE 1


Operating Specifications

Step Angle: 1.8°

Maximum Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min







Torque Curves













Submodels

Model Holding Torque Step Angle Motor Length Type of Shaft Rated Current
42SHD4950 0.13N.m 1.8° 20mm D Shaft-20mm 1.0A
42SHD4003 0.26N.m 1.8° 34mm D Shaft-20mm 0.4A
42SHD0261 0.45N.m 1.8° 40mm D Shaft-20mm 1.68A
42SHD4425 0.59N.m 1.8° 48mm D Shaft-24mm 2.0A
42SHD4813 0.8N.m 1.8° 60mm D Shaft-24mm 2.1A





Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:

Encoder

Brake

Gearbox

Shaft
Waterproof Grade IP65 Stepping Motor 1.0A 0.22N.m 42×42×42.6mm NEMA 17 With ISO CE 2 Waterproof Grade IP65 Stepping Motor 1.0A 0.22N.m 42×42×42.6mm NEMA 17 With ISO CE 3 Waterproof Grade IP65 Stepping Motor 1.0A 0.22N.m 42×42×42.6mm NEMA 17 With ISO CE 4 Waterproof Grade IP65 Stepping Motor 1.0A 0.22N.m 42×42×42.6mm NEMA 17 With ISO CE 5



Please click the "Get a quote" button below to tell us your requirements.
