Casun Hybrid Stepper Motor Nema16 105mN.m 8.75V High Quality Stepping Motor with Encoder and Gear

Casun Hybrid Stepper Motor Nema16 105mN.m 8.75V High Quality Stepping Motor with Encoder and Gear

Brand Name:	Casun
Model Number:	39SHE6320-24AQ
MOQ:	5PC
Price:	$23.4~$25.36
Payment Terms:	D/A, T/T, L/C, D/P
Supply Ability:	10000+PCS+Month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE,ROHS,ISO

Holding Torque:

105 MN.m

Voltage:

8.75V

Current:

0.5A

Body Length:

32mm

Weight:

0.18 Kg

Phase Resistance:

12.5 Ohm ±10% （At 20℃）

Shaft Length:

24 Mm

Phase:

Insulation Class:

Class B

Packaging Details:

Carton:38x29x18cm

Product Description

Casun Hybrid Stepper Motor Nema16 105 mN.m 8.75 V High Quality Stepping Motor with Encoder and Gear

The Casun Nema16 Hybrid Stepper Motor combines encoder feedback and precision gearing to deliver exceptional motion control in a compact package. With 105 mN.m torque and 8.75 V operation, this motor is engineered for robotics, automation, and high-accuracy positioning systems where reliability and performance are critical.

Features:

Bipolar or unipolar versions available
Hybrid stepper construction
Available in single- or double-shaft versions
CE and RoHS approved
Customizations on request

Dimensions

Casun Hybrid Stepper Motor Nema16 105mN.m 8.75V High Quality Stepping Motor with Encoder and Gear 0

Motor Specifications

Step Angel	1.8°
Frame Size	32 mm
Number of Phase	2 Phase
Rated Current	0.5 Amp
Holding Torque	105 mN.m
Resistance	17.5 ohm
Inductance	9.6 mH
Rotor Inertia	20 g.cm²
Motor weight	0.18 kg
Connection	Bipolar

Operating Specifications

Motor

Step Angle: 1.8°

Maximum Temperature: 80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range: 85% or less, non-condensing

Magnet Wire Insulation: Class B 130 deg C

Insulation Resistance: 100M Ohm at 500 VDC

Dielectric Strength: 500 VDC for 1 min

Encoder

Voltage: 5 v

Output: A + A - B + B - Z + Z -

Submodels

Casun Hybrid Stepper Motor Nema16 105mN.m 8.75V High Quality Stepping Motor with Encoder and Gear 1

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Shaft

Casun Hybrid Stepper Motor Nema16 105mN.m 8.75V High Quality Stepping Motor with Encoder and Gear 2

Please click the "Get a quote" button below to tell us your requirements.
