Close Loop Stepper Motor
Created with Pixso.

2NM 76mm NEMA 23 Closed Loop Motor 2500ppr Hybrid Stepper Motor

name

2NM 76mm NEMA 23 Closed Loop Motor 2500ppr Hybrid Stepper Motor

Brand Name: Casun
Model Number: 57SHD4816-20BQH
MOQ: 1PC
Price: $23.94-$28.34
Payment Terms: D/A, T/T, L/C, D/P
Supply Ability: 40000+PCS+Month
Detail Information
Product Description
Detail Information
Place of Origin:
CHINA
Certification:
CE,ROHS,ISO
Color:
Black
Current:
3Amp
Holding Torque:
2000mN.m
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Packaging Details:
Carton:38x29xc14m
Highlight:

76mm NEMA 23 Closed Loop Motor

,

2NM NEMA 23 Closed Loop Motor

,

2500ppr Hybrid Stepper Motor

Product Description

Nema 23 Closed-Loop Stepper Motor 57X57MM 76mm Step Motor 2.0NM 2500ppr Hybrid Closed Loop Step Motor

The 42mm Hybrid Stepper Motor Series offers powerful holding torque in a variety of sizes.

Use with a microstepping driver to reduce vibration and achieve higher step resolution.

Choose a baseline version or request your own customized configuration.



Features:

  • Bipolar or unipolar versions available

  • Hybrid stepper construction

  • Available in single or double shaft versions

  • CE and RoHS approved

  • Customizations on request

Dimensions

2NM 76mm NEMA 23 Closed Loop Motor 2500ppr Hybrid Stepper Motor 0







Motor Specifications



Step Angel



1.8 °

Fram Size



57mm

Number of Phase



2 Phase

Rated Current



3Amp

Holding Torque



2000mN.m

Resistance



0.95ohm

Inductance



3.6mH

Rotor Inertia



460g-cm²

Motor weight



1.1kg

D Shaft



20mm

Connection



Bipolar



Operating Specifications





Step Angle: 1.8°

Maximum  Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min

Shaft Radial Play:0.02Max. (450g-load)

Shaft Axial Play:0.08Max. (450g-load)

Max. radial force:28N (20mm from the flange)

Max. axial force):10N







Torque Curves





Submodels



Model Holding Torque Step Angle Motor Length Type of Shaft Rated Current
42SHD4950 0.13N.m 1.8° 20mm D Shaft-20mm 1.0A
42SHD4003 0.26N.m 1.8° 34mm D Shaft-20mm 0.4A
42SHD0261 0.45N.m 1.8° 40mm D Shaft-20mm 1.68A
42SHD4425 0.59N.m 1.8° 48mm D Shaft-24mm 2.0A
42SHD4813 0.8N.m 1.8° 60mm D Shaft-24mm 2.1A





Body Length Diameter of Screw Pitch Length of Screw
20 mm

34 mm

40 mm

48 mm

60 mm
 		 5 2 20-1000 mm
8
6.35 1.27
3.175
6.35
6.5 3
6.35
8 1
2
4
8
12



Download







If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
            Encoder          |               Brake           |              Gearbox            |           Shaft

2NM 76mm NEMA 23 Closed Loop Motor 2500ppr Hybrid Stepper Motor 1 2NM 76mm NEMA 23 Closed Loop Motor 2500ppr Hybrid Stepper Motor 2 2NM 76mm NEMA 23 Closed Loop Motor 2500ppr Hybrid Stepper Motor 3 2NM 76mm NEMA 23 Closed Loop Motor 2500ppr Hybrid Stepper Motor 4





Please click the "Get  a quote" button below to tell us your requirements.











Tags:

76mm NEMA 23 Closed Loop Motor

2NM NEMA 23 Closed Loop Motor

2500ppr Hybrid Stepper Motor
