Pancake Stepper Motor
Created with Pixso.

Casun Pancake Steppper Motor 57x57x13mm Flat With High Stepper Motor

name

Casun Pancake Steppper Motor 57x57x13mm Flat With High Stepper Motor

Brand Name: Casun
Model Number: 42SHY4102-2A1
MOQ: 1PC
Price: $8-$10.84
Payment Terms: D/A, T/T, L/C, D/P
Supply Ability: 40000+PCS+Month
Detail Information
Product Description
Detail Information
Place of Origin:
CHINA
Certification:
CE,ROHS,ISO
Prouct:
Nema57
Holding Torque:
36mN.m
Rated Current:
0.5A
Voltage:
5.2V DC
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Packaging Details:
Carton:36x29x14cm
Highlight:

Pancake Steppper Motor 57x57x13mm

,

Flat Pancake Steppper Motor

Product Description

Casun pancake steppper motor 57x57x13mm flat stepper motor with high stepper motor



NEMA17 Flat stepper motor 42mmx42mmx19.8mm pancake step motor for medical beauty equipment robotics

The  Hybrid Stepper Motor Series offers powerful holding torque in a variety of sizes.

Use with a microstepping driver to reduce vibration and achieve higher step resolution.

Choose a baseline version or request your own customized configuration.



Features:

  • Bipolar or unipolar versions available

  • Hybrid stepper construction

  • Available in single or double shaft versions

  • CE and RoHS approved

  • Customizations on request

Dimensions Casun Pancake Steppper Motor 57x57x13mm Flat With High Stepper Motor 0

Casun Pancake Steppper Motor 57x57x13mm Flat With High Stepper Motor 1





Casun Pancake Steppper Motor 57x57x13mm Flat With High Stepper Motor 2

Motor Specifications



Step Angel



1.8 °

Fram Size



42mm

Number of Phase



2 Phase

Rated Current



0.5A

Holding Torque



36mN.m

Resistance



3.5 om

Inductance



1.8mH

Rotor Inertia



12 g-cm²

Motor weight



0.06kg

Number of leads



4

Connection



Bipolar



Operating Specifications





Step Angle: 1.8°

Maximum  Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min









Torque Curves





Submodels



Model Motor Length Current Holding Torque
P28SHD4611 9.5mm 0.5A 16mN.m
P28SHD4701 10.6mm 0.5A 20mN.m
P28SHD4750 13-15mm 0.5A 25mN.m
P28SHD4950 17.9mm 0.5A 35mN.m


Download





If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
            Encoder          |               Brake           |              Gearbox            |           Shaft

Casun Pancake Steppper Motor 57x57x13mm Flat With High Stepper Motor 3 Casun Pancake Steppper Motor 57x57x13mm Flat With High Stepper Motor 4 Casun Pancake Steppper Motor 57x57x13mm Flat With High Stepper Motor 5 Casun Pancake Steppper Motor 57x57x13mm Flat With High Stepper Motor 6





Please click the "Get  a quote" button below to tell us your requirements.
