Nema 34 Stepper Motor Kit 3 Axis 12N.M CNC High Resolution Stepper Motor

Nema 34 Stepper Motor Kit 3 Axis 12N.M CNC Kit High Resolution Stepper Motor

NEMA 34 12N.m Opening Loop Stepper Motor kit 4 motor+4 Driver+4 Power supply+1 mach3

Stepper Motor Cables: These cables are used to connect the stepper motors to the motor drivers, transferring power and control signals.

Limit Switches: Limit switches are used to set the physical boundaries of the CNC machine's movement. They signal the controller when the machine reaches its maximum or minimum position on each axis.


Magnetic Encoders: As mentioned earlier, magnetic encoders are included in closed-loop stepper motor kits. They provide feedback on the motor's position and help maintain the accuracy of movements.


Spindle Motor (optional): In some CNC kits, a spindle motor may be included for controlling the rotation of a cutting tool or spindle. This is typically used in applications such as CNC milling or routing.


Cooling System (optional): Depending on the kit and the specific requirements of the CNC machine, a cooling system such as a fan or heat sink might be included to prevent overheating of the motor drivers or other components.


Software: Some CNC kits may also come with software for controlling and programming the CNC machine. This software allows users to generate G-code, simulate toolpaths, and send commands to the CNC controller.


Features:

• High torque and high precision

• For high-tech industry and electronic industry equipment

• Available in single or double shaft versions

• Established in China for 12 years and has served more than 800 customers.

• Professional research and development manufacturing

Motor Specifications

Operating Specifications

Step Angle: 1.8°

Maximum  Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min

Torque Curves

Submodels

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:

Encoder	Brake	Gearbox	Shaft

Please click the "Get a quote" button below to tell us your requirements.
