Nema 17 Encoder Stepper Motor 42x40mm 500mN.M 200ppr Step Motor For 3D Printer

Nema 17 Encoder Stepper Motor 42x40mm 500mN.M 200ppr Step Motor For 3D Printer

Brand Name:	Casun
Model Number:	42SHD0217-24Q
MOQ:	1PC
Price:	$16.54-$24.94
Payment Terms:	D/A, T/T, L/C, D/P
Supply Ability:	40000+PCS+Month

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

CE,ROHS,ISO

Color:

Black

Current / Phase:

1.5Amp

Holding Torque:

500mN.m

Customized:

The Motor Can Be Designed &manufactured With Customized Request.

Packaging Details:

Carton:38x29x18cm

Highlight:

Nema 17 Encoder Stepper Motor

500mN.M Encoder Stepper Motor

Product Description

Nema 17 Encoder Stepper Motor 42x40mm 500mN.M 200ppr Step Motor For 3D Printer

The NEMA 17 42x40mm stepper motor with 500mN.m torque and 200ppr (pulses per revolution) is a high-performance closed loop stepper motor designed for precision applications such as 3D printers, robotics, CNC machines, and automation systems.

Key Features

Bipolar or unipolar versions available
Hybrid stepper construction
Available in single or double shaft versions
CE and RoHS approved
Customizations on request

Dimensions

Motor Specifications

Specification	Value
Step Angle	1.8°
Frame Size	42 mm
Number of Phase	2 Phase
Rated Current	1.5Amp
Holding Torque	500mN.m
Resistance	3.2 Ω
Inductance	2.7mH
Rotor Inertia	12g-cm²
Motor Weight	0.23 kg
Encoder Pulse	200PPR
Connection	Bipolar

Operating Specifications

Motor

Step Angle	1.8°
Maximum Temperature	80°C maximum
Ambient Temperature	-20°C to 50°C
Storage Temperature	-20°C to 100°C
Humidity Range	85% or less, non-condensing
Magnet Wire Insulation	Class B 130°C
Insulation Resistance	100M Ohm at 500 VDC
Dielectric Strength	500 VDC for 1 min

Encoder

Voltage	5V
Output	A + A - B + B - Z + Z -

Submodels

Model	Holding Torque	Step Angle	Length	Type of Shaft	Rated Current
42SHD4950	0.13N.m	1.8°	20mm	D Shaft-20mm	1.0A
42SHD4003	0.26N.m	1.8°	34mm	D Shaft-20mm	0.4A
42SHD0261	0.45N.m	1.8°	40mm	D Shaft-20mm	1.68A
42SHD4425	0.59N.m	1.8°	48mm	D Shaft-24mm	2.0A
42SHD4813	0.8N.m	1.8°	60mm	D Shaft-24mm	2.1A

Customization Options

If our standard motor cannot meet your needs, we can customize the motor according to your requirements. Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Encoder

Brake

Gearbox

Shaft
