360mN.M 42x40mm Close Loop Stepper Motor Nema 17 With 1000 Ppr Encoder For Automation Equipment

360mN.M 42x40mm Close Loop Stepper Motor Nema 17 With 1000 Ppr Encoder For Automation Equipment

360mN.M Close Loop Stepper Motor

Close Loop Stepper Motor Nema 17

Place of Origin:

CHINA

Brand Name:

Casun

Certification:

CE,ROHS,ISO

Model Number:

42SHD4260-22Q

Contact Us

Request A Quote
Product Details
Color:
Black
Current / Phase:
1.65Amp
Holding Torque:
360mN.m
Motor Length:
40mm
Payment & Shipping Terms
Minimum Order Quantity
1PC
Price
$15.54-$30.94
Packaging Details
Carton:38x29x18cm
Delivery Time
7-15 days
Payment Terms
D/A, T/T, L/C, D/P
Supply Ability
40000+PCS+Month
RELATED PRODUCTS
Contact Us
86-020-36907671
Contact Now
Product Description

Casun Closed Loop Stepper Motor360mN.M 42x40mm Stepper Motor With Nema 17 Stepper Motor Controller

Encoder Step Motor 360mN.M 42x40mm Close Loop Stepper Motor Nema 17 With 1000 Ppr Encoder For Automation Equipment

Nema17 Closed Loop Stepper Motor 360mN.m 1.65Amp with Encoder

The Casun Closed Loop Stepper Motor you mentioned is a specific model of stepper motor manufactured by Casun Motors. It has a holding torque of 360mN.m and a size of 42x40mm. The term "closed loop" indicates that this stepper motor incorporates a feedback mechanism to ensure accurate positioning.

In addition to the stepper motor itself, a Nema 17 Stepper Motor Controller. Nema 17 refers to the mounting standard for stepper motors, indicating the motor's faceplate size. The stepper motor controller is a device that provides control signals to the stepper motor, allowing you to control its speed, direction, and position.

By using a closed loop stepper motor and a dedicated stepper motor controller, you can achieve more precise control over the motor's position by providing feedback on its actual position and making adjustments as necessary.

Features:

  • Bipolar or unipolar versions available

  • Hybrid stepper construction

  • Available in single or double shaft versions

  • CE and RoHS approved

  • Customizations on request

Dimensions

360mN.M 42x40mm Close Loop Stepper Motor Nema 17 With 1000 Ppr Encoder For Automation Equipment 0







Motor Specifications



Step Angel



1.8 °

Fram Size



42 mm

Number of Phase



2 Phase

Rated Current



1.65Amp

Holding Torque



360mN.m

Resistance



0.72hm

Inductance



1.44mH

Rotor Inertia



57g-cm²

Motor weight



0.28 kg

Encoder Pulsh



1000PPR

Connection



Bipolar



Operating Specifications



Motor



Step Angle: 1.8°

Maximum  Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min



Encoder







Voltage: 5 v

Output: A + A - B + B -











Torque Curves









Submodels

Model Holding Torque Step Angle Length Type of Shaft Rated Current
42SHD4950 0.13N.m 1.8° 20mm D Shaft-20mm 1.0A
42SHD4003 0.26N.m 1.8° 34mm D Shaft-20mm 0.4A
42SHD0261 0.45N.m 1.8° 40mm D Shaft-20mm 1.68A
42SHD4425 0.59N.m 1.8° 48mm D Shaft-24mm 2.0A
42SHD4813 0.8N.m 1.8° 60mm D Shaft-24mm 2.1A

Download



If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
            Encoder          |               Brake           |              Gearbox            |           Shaft

360mN.M 42x40mm Close Loop Stepper Motor Nema 17 With 1000 Ppr Encoder For Automation Equipment 1 360mN.M 42x40mm Close Loop Stepper Motor Nema 17 With 1000 Ppr Encoder For Automation Equipment 2 360mN.M 42x40mm Close Loop Stepper Motor Nema 17 With 1000 Ppr Encoder For Automation Equipment 3 360mN.M 42x40mm Close Loop Stepper Motor Nema 17 With 1000 Ppr Encoder For Automation Equipment 4





Please click the "Get  a quote" button below to tell us your requirements.
