0.9 Degree 400 Ppr Encoder Step Motor 440mN.M 42x48mm Close Loop Nema 17

0.9 Degree 400 Ppr Encoder Step Motor 440mN.M 42x48mm Close Loop Nema 17

Brand Name:	Casun
Model Number:	42SHD4602-20Q
MOQ:	1PC
Price:	$15.54-$30.94
Payment Terms:	D/A, T/T, L/C, D/P
Supply Ability:	40000+PCS+Month

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

CE,ROHS,ISO

Color:

Black

Current / Phase:

1.68Amp

Holding Torque:

440mN.m

Motor Length:

48mm

Customized:

The Motor Can Be Designed &manufactured With Customized Request.

Packaging Details:

Carton:38x29x18cm

Highlight:

0.9 Degree Encoder Step Motor

440mN.M Encoder Step Motor

Close Loop Encoder Step Motor 4

Product Description

0.9 Degree 400 PPR Encoder Step Motor 440mN.M 42x48mm Close Loop Nema 17

0.9 degree Casun Closed Loop Stepper Motor 440mN.M 42x48mm Stepper Motor with Nema 17 Stepper Motor Controller.

This Nema17 Closed Loop Stepper Motor provides precise positioning and control with a 0.9-degree step angle, allowing for more accurate positioning compared to motors with larger step angles. The holding torque of 440mN.m ensures reliable performance without losing steps.

Key Features

Bipolar or unipolar versions available
Hybrid stepper construction
Available in single or double shaft versions
CE and RoHS approved
Customizations on request

Dimensions

Motor Specifications

Specification	Value
Step Angle	1.8°
Frame Size	42 mm
Number of Phase	2 Phase
Rated Current	1.68Amp
Holding Torque	440mN.m
Resistance	1.65Ω
Inductance	4.8mH
Rotor Inertia	72g-cm²
Motor Weight	0.38 kg
Encoder Pulse	400PPR
Connection	Bipolar

Operating Specifications

Motor

Parameter	Specification
Step Angle	1.8°
Maximum Temperature	80°C maximum
Ambient Temperature	-20°C to 50°C
Storage Temperature	-20°C to 100°C
Humidity Range	85% or less, non-condensing
Magnet Wire Insulation	Class B 130°C
Insulation Resistance	100M Ohm at 500 VDC
Dielectric Strength	500 VDC for 1 min

Encoder

Parameter	Specification
Voltage	5V
Output	A + A - B + B -
Customization	Available

Submodels

Model	Holding Torque	Step Angle	Length	Type of Shaft	Rated Current
42SHD4950	0.13N.m	1.8°	20mm	D Shaft-20mm	1.0A
42SHD4003	0.26N.m	1.8°	34mm	D Shaft-20mm	0.4A
42SHD0261	0.45N.m	1.8°	40mm	D Shaft-20mm	1.68A
42SHD4425	0.59N.m	1.8°	48mm	D Shaft-24mm	2.0A
42SHD4813	0.8N.m	1.8°	60mm	D Shaft-24mm	2.1A

Customization Options

If our standard motor cannot meet your needs, we can customize the motor according to your requirements. Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Available Options

Encoder

Brake

Gearbox

Shaft

Please click the "Get a quote" button below to tell us your requirements.
