1.8 Degree Nema 23 Closed Loop Stepper Motor 2400mN.M 1024pps

1.8 Degree Nema 23 Closed Loop Stepper Motor 2400mN.M 1024pps

Nema 23 Closed Loop Stepper Motor

1.8 Degree Closed Loop Stepper Motor

2400mN.M Closed Loop Stepper Motor

Place of Origin:

CHINA

Brand Name:

Casun

Certification:

CE,ROHS,ISO

Model Number:

42SHD4419-24Q

Contact Us

Request A Quote
Product Details
Color:
Black
Current / Phase:
1.68Amp
Holding Torque:
2400mN.m
Motor Length:
76mm
Payment & Shipping Terms
Minimum Order Quantity
1PC
Price
$18.54-$30.94
Packaging Details
Carton:38x29x18cm
Delivery Time
7-15 days
Payment Terms
D/A, T/T, L/C, D/P
Supply Ability
40000+PCS+Month
RELATED PRODUCTS
Contact Us
86-020-36907671
Contact Now
Product Description

1. 8 degree Casun Closed Loop Stepper Motor 2400mN.M 57x76mm Stepper Motor With Nema 23 Stepper Motor Controller



Nema23 Closed Loop Stepper Motor 240mN.m 3Amp with Encoder

Nema 23 is a standard specification for stepper motors that defines the mounting dimensions. It indicates that the motor has a faceplate size of 2.3 x 2.3 inches or approximately 57 x 57mm. Nema 23 motors are commonly used in various applications that require moderate torque and accurate positioning.


Features:

  • Bipolar or unipolar versions available

  • Hybrid stepper construction

  • Available in single or double shaft versions

  • CE and RoHS approved

  • Customizations on request

Dimensions

1.8 Degree Nema 23 Closed Loop Stepper Motor 2400mN.M 1024pps 0







Motor Specifications



Step Angel



1.8 °

Fram Size



57mm

Number of Phase



2Phase

Rated Current



3Amp

Holding Torque



240mN.m

Resistance



3.3hm

Inductance



2.8mH

Rotor Inertia



72g-cm²

Motor weight



1 kg

Encoder Pulsh



1240PPS

Connection



Bipolar



Operating Specifications



Motor



Step Angle: 1.8°

Maximum  Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min



Encoder



                                                                                                            can customized



Voltage: 5 v

Output: A + A - B + B -











Torque Curves









Submodels

Model Holding Torque Step Angle Length Type of Shaft Rated Current
42SHD4950 0.13N.m 1.8° 20mm D Shaft-20mm 1.0A
42SHD4003 0.26N.m 1.8° 34mm D Shaft-20mm 0.4A
42SHD0261 0.45N.m 1.8° 40mm D Shaft-20mm 1.68A
42SHD4425 0.59N.m 1.8° 48mm D Shaft-24mm 2.0A
42SHD4813 0.8N.m 1.8° 60mm D Shaft-24mm 2.1A

Download



If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
            Encoder          |               Brake           |              Gearbox            |           Shaft

1.8 Degree Nema 23 Closed Loop Stepper Motor 2400mN.M 1024pps 1 1.8 Degree Nema 23 Closed Loop Stepper Motor 2400mN.M 1024pps 2 1.8 Degree Nema 23 Closed Loop Stepper Motor 2400mN.M 1024pps 3 1.8 Degree Nema 23 Closed Loop Stepper Motor 2400mN.M 1024pps 4
