Home > products > Multilayer Motor > NEMA 17 Double Layer Linear Stepper Motor 12V With Precision Positioning
NEMA 17 Double Layer Linear Stepper Motor 12V With Precision Positioning
NEMA 17 Double Layer Linear Stepper Motor 12V With Precision Positioning
NEMA 17 Double Layer Linear Stepper Motor 12V With Precision Positioning
NEMA 17 Double Layer Linear Stepper Motor 12V With Precision Positioning
NEMA 17 Double Layer Linear Stepper Motor 12V With Precision Positioning
NEMA 17 Double Layer Linear Stepper Motor 12V With Precision Positioning
NEMA 17 Double Layer Linear Stepper Motor 12V With Precision Positioning

NEMA 17 Double Layer Linear Stepper Motor 12V With Precision Positioning

Product Details

Place of Origin: CHINA

Brand Name: Casun

Certification: CE,ROHS,ISO

Model Number: S42-02

Payment & Shipping Terms

Minimum Order Quantity: 1PC

Price: $11-$15

Packaging Details: Carton:36x29x14cm

Delivery Time: 7-15 days

Payment Terms: D/A, T/T, L/C, D/P

Supply Ability: 40000+PCS+Month

Get Best Price

Product Details

Product Description
Product Details
High Light:

Double Layer Linear Stepper Motor

,

NEMA 17 Linear Stepper Motor

,

Linear Stepper Motor Precision Positioning

Step Angel:
1.8°
Holding Torque:
280mN.m
Current:
0.4A
Motor Length:
34mm
Stroke:
0~37
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Step Angel:
1.8°
Holding Torque:
280mN.m
Current:
0.4A
Motor Length:
34mm
Stroke:
0~37
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Product Description

NEMA 17 Double Layer Linear Stepper Motor 12V With Precision Positioning

The double-layer stepper motor can achieve precise rotation and position control.

Double layer linear motors are widely used in the field of automation control.



Features:

  • Operating in China for 12 years, having served over 800 customers

  • Dealers needed! !

  • Supply "multiple international certifications" for high-tech and electronic industry equipment

  • Specializing in drivetrain solutions

  • Expertise in research, development, and production

Motor Specifications

Step Angel

1.8 °

Fram Size

42 mm

Number of Phase

2 Phase

Rated Current

0.4 A

Holding Torque

280 mN.m

Resistance

30 ohm

Inductance

37 mH

Rotor Inertia38

 g-cm²

Motor weight

0.4 kg

Number of leads

4

Connection

Bipolar

Appearance

NEMA 17 Double Layer Linear Stepper Motor 12V With Precision Positioning 0

Dimensions

NEMA 17 Double Layer Linear Stepper Motor 12V With Precision Positioning 1


Operating Specifications

Step Angle: 1.8°

Maximum  Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min







Torque Curves













Submodels

Model Holding Torque Step Angle Motor Length Type of Shaft Rated Current
42SHD4950 0.13N.m 1.8° 20mm D Shaft-20mm 1.0A
42SHD4003 0.26N.m 1.8° 34mm D Shaft-20mm 0.4A
42SHD0261 0.45N.m 1.8° 40mm D Shaft-20mm 1.68A
42SHD4425 0.59N.m 1.8° 48mm D Shaft-24mm 2.0A
42SHD4813 0.8N.m 1.8° 60mm D Shaft-24mm 2.1A





Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:

Encoder

Brake

Gearbox

Shaft
NEMA 17 Double Layer Linear Stepper Motor 12V With Precision Positioning 2 NEMA 17 Double Layer Linear Stepper Motor 12V With Precision Positioning 3 NEMA 17 Double Layer Linear Stepper Motor 12V With Precision Positioning 4 NEMA 17 Double Layer Linear Stepper Motor 12V With Precision Positioning 5



Please click the "Get a quote" button below to tell us your requirements.



Tags:

Double Layer Linear Stepper Motor,

NEMA 17 Linear Stepper Motor,

Linear Stepper Motor Precision Positioning
