Nema 23 Flat Stepper Motor 57×57×13mm 1.3A for YAMAHA
  • Nema 23 Flat Stepper Motor 57×57×13mm 1.3A for YAMAHA
  • Nema 23 Flat Stepper Motor 57×57×13mm 1.3A for YAMAHA
  • Nema 23 Flat Stepper Motor 57×57×13mm 1.3A for YAMAHA
  • Nema 23 Flat Stepper Motor 57×57×13mm 1.3A for YAMAHA
  • Nema 23 Flat Stepper Motor 57×57×13mm 1.3A for YAMAHA
  • Nema 23 Flat Stepper Motor 57×57×13mm 1.3A for YAMAHA

Nema 23 Flat Stepper Motor 57×57×13mm 1.3A for YAMAHA

Place of Origin CHINA
Brand Name Casun
Certification CE,ROHS,ISO
Model Number 57SHY4301-10B1
Product Details
Step Angle:
1.8°
Body:
13mm
Current:
1.2A
Holding Torque:
125mN.m
Shaft:
Milling Flat Shaft 10mm Length
Payment & Shipping Terms
Minimum Order Quantity
1PC
Price
$9.68-13.46
Packaging Details
Carton:36x29x14cm
Delivery Time
7-15 days
Payment Terms
D/A, T/T, L/C, D/P
Supply Ability
40000+PCS+Month
Product Description

Due to fewer internal voids, the heat dissipation and conduction performance are better.

Use with a microstepping driver to reduce vibration and achieve higher step resolution.



Features:

  • Bipolar or unipolar versions available

  • Each model of our stepper motors is designed to fit various application scenarios

  • Available in single or double shaft versions

  • CE and RoHS approved

  • We have been established in China for 12 years and have served over 800 clients

Dimensions

Nema 23 Flat Stepper Motor 57×57×13mm 1.3A for YAMAHA 0







Motor Specifications



Step Angel



1.8 °

Fram Size



57 mm

Number of Phase



2 Phase

Rated Current



1.2A

Holding Torque



125 mN.m

Resistance



1.8 om

Inductance



1.2 mH

Rotor Inertia



20 g-cm²

Motor weight



0.08 kg

Number of leads



4

Connection



Bipolar



Operating Specifications





Step Angle: 1.8°

Maximum  Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min









Torque Curves





Submodels



Model Motor Length Current Holding Torque
57SHY4001 9.6mm 0.8A 60mN.m
57SHY4301 13mm 1.2A 125mN.m




Download





If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.
