GUANGZHOU FUDE ELECTRONIC TECHNOLOGY CO.,LTD Company Profile
products
Home > products > Close Loop Stepper Motor > 28X28X45mm 1.8 Degree 2 Phase NEMA 11 Stepper Motor With Encoder Close Loop Servo Motor
28X28X45mm 1.8 Degree 2 Phase NEMA 11 Stepper Motor With Encoder Close Loop Servo Motor
28X28X45mm 1.8 Degree 2 Phase NEMA 11 Stepper Motor With Encoder Close Loop Servo Motor
28X28X45mm 1.8 Degree 2 Phase NEMA 11 Stepper Motor With Encoder Close Loop Servo Motor
28X28X45mm 1.8 Degree 2 Phase NEMA 11 Stepper Motor With Encoder Close Loop Servo Motor
28X28X45mm 1.8 Degree 2 Phase NEMA 11 Stepper Motor With Encoder Close Loop Servo Motor
28X28X45mm 1.8 Degree 2 Phase NEMA 11 Stepper Motor With Encoder Close Loop Servo Motor
28X28X45mm 1.8 Degree 2 Phase NEMA 11 Stepper Motor With Encoder Close Loop Servo Motor

28X28X45mm 1.8 Degree 2 Phase NEMA 11 Stepper Motor With Encoder Close Loop Servo Motor

Product Details

Place of Origin: CHINA

Brand Name: Casun

Certification: CE,ROHS,ISO

Model Number: 28SHD4414-15BQ

Payment & Shipping Terms

Minimum Order Quantity: 1PC

Packaging Details: Carton:38x29x18cm

Delivery Time: 7-15 days

Payment Terms: D/A, T/T, L/C, D/P

Supply Ability: 40000+PCS+Month

Get Best Price

Product Details

Product Description
Product Details
Highlight:

28X28X45mm NEMA 11 Stepper Motor

,

1.8 Degree NEMA 11 Stepper Motor

,

Encoder NEMA 11 Stepper Motor

Color:
Black
Current / Phase:
0.95Amp
Holding Torque:
98mN.m
Weight:
0.14 Kg
Size:
NEMA 11
Rated Current:
0.95 A
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Color:
Black
Current / Phase:
0.95Amp
Holding Torque:
98mN.m
Weight:
0.14 Kg
Size:
NEMA 11
Rated Current:
0.95 A
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Product Description

Motors with reducers can achieve more complex motion control, such as precise adjustment of speed and position.

Applied to precision positioning, laboratory equipment, medical equipment.



Features:

  • Bipolar or unipolar versions available

  • Hybrid stepper construction

  • Expert in drivetrain solutions

  • Our engineering team will reach out within 48 hours to deliver the optimal solution

  • Customizations on request

Dimensions

28X28X45mm 1.8 Degree 2 Phase NEMA 11 Stepper Motor With Encoder Close Loop Servo Motor 0







Motor Specifications



Step Angel



1.8 °

Fram Size



42 mm

Number of Phase



2 Phase

Rated Current



0.95Amp

Holding Torque



98mN.m

Resistance



3.2 hm

Inductance



2.7mH

Rotor Inertia



12g-cm²

Motor weight



0.14 kg

Encoder Pulsh



2500

Connection



Bipolar



Operating Specifications



Motor



Step Angle: 1.8°

Maximum  Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min



Encoder







Voltage: 5 v

Output: A + A - B + B - Z + Z -













Torque Curves









Submodels

Model Holding Torque Step Angle Length Type of Shaft Rated Current
42SHD4950 0.13N.m 1.8° 20mm D Shaft-20mm 1.0A
42SHD4003 0.26N.m 1.8° 34mm D Shaft-20mm 0.4A
42SHD0261 0.45N.m 1.8° 40mm D Shaft-20mm 1.68A
42SHD4425 0.59N.m 1.8° 48mm D Shaft-24mm 2.0A
42SHD4813 0.8N.m 1.8° 60mm D Shaft-24mm 2.1A

Download



If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
            Encoder          |               Brake           |              Gearbox            |           Shaft

28X28X45mm 1.8 Degree 2 Phase NEMA 11 Stepper Motor With Encoder Close Loop Servo Motor 1 28X28X45mm 1.8 Degree 2 Phase NEMA 11 Stepper Motor With Encoder Close Loop Servo Motor 2 28X28X45mm 1.8 Degree 2 Phase NEMA 11 Stepper Motor With Encoder Close Loop Servo Motor 3 28X28X45mm 1.8 Degree 2 Phase NEMA 11 Stepper Motor With Encoder Close Loop Servo Motor 4





Please click the "Get  a quote" button below to tell us your requirements.
