NEMA 17 Closed Loop Stepper Motor With Encoder 42x42x48mm 1.2A For Robot Accessories

name

NEMA 17 Closed Loop Stepper Motor With Encoder 42x42x48mm 1.2A For Robot Accessories

Brand Name: Casun
Model Number: 42SHD6428-24Q
MOQ: 1PC
Price: $3.14-$5
Payment Terms: D/A, T/T, L/C, D/P
Supply Ability: 40000+PCS+Month
Detail Information
Product Description
Detail Information
Place of Origin:
CHINA
Certification:
CE,ROHS,ISO
Step Angel:
1.8°
Holding Torque:
400mN.m
Current:
1.2A
Motor Length:
48mm
Packaging Details:
Carton:36x29x14cm
Highlight:

NEMA 17 Closed Loop Stepper Motor

,

1.2A Closed Loop Stepper Motor

,

Robot Accessories Closed Loop Stepper Motor

Product Description

Motors with encoders can achieve more complex motion control, such as precise adjustment of speed and position.

The applications in medical equipment include the positioning of precision surgical tools and the adjustment of patient support platforms.



Features:

  • Every stepper motor model has use in a variety of situations.

  • Needed dealers! !

  • Accept contract manufacturing

  • High torque and high precision

  • Each stepper motor model is adaptable to various scenarios





Motor Specifications



Step Angel

1.8 °

Fram Size

42 mm

Number of Phase

2 Phase

Rated Current

1.2 A

Holding Torque

400 mN.m

Resistance

2.8 ohm

Inductance

3.1 mH

Rotor Inertia

72 g-cm²

Motor weight

0.2 kg

Number of leads

4

Connection

Bipolar

Appearance

NEMA 17 Closed Loop Stepper Motor With Encoder 42x42x48mm 1.2A For Robot Accessories 0

Dimensions

NEMA 17 Closed Loop Stepper Motor With Encoder 42x42x48mm 1.2A For Robot Accessories 1


Operating Specifications

Step Angle: 1.8°

Maximum  Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min







Torque Curves













Submodels

Model Holding Torque Step Angle Motor Length Type of Shaft Rated Current
42SHD4950 0.13N.m 1.8° 20mm D Shaft-20mm 1.0A
42SHD4003 0.26N.m 1.8° 34mm D Shaft-20mm 0.4A
42SHD0261 0.45N.m 1.8° 40mm D Shaft-20mm 1.68A
42SHD4425 0.59N.m 1.8° 48mm D Shaft-24mm 2.0A
42SHD4813 0.8N.m 1.8° 60mm D Shaft-24mm 2.1A





Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:

Encoder

Brake

Gearbox

Shaft
NEMA 17 Closed Loop Stepper Motor With Encoder 42x42x48mm 1.2A For Robot Accessories 2 NEMA 17 Closed Loop Stepper Motor With Encoder 42x42x48mm 1.2A For Robot Accessories 3 NEMA 17 Closed Loop Stepper Motor With Encoder 42x42x48mm 1.2A For Robot Accessories 4 NEMA 17 Closed Loop Stepper Motor With Encoder 42x42x48mm 1.2A For Robot Accessories 5



Please click the "Get a quote" button below to tell us your requirements.
