Geared Stepper Motor
Created with Pixso.

NEMA17 Ratio 99.5/1 Planetary Gearbox Stepper Motor 0.44mN.m For Cnc Robot Arm

NEMA17 Ratio 99.5/1 Planetary Gearbox Stepper Motor 0.44mN.m For Cnc Robot Arm

Brand Name: Casun
Model Number: 42SHD4419-100G
MOQ: 1PC
Price: $16.49-$24.14
Payment Terms: D/A, T/T, L/C, D/P
Supply Ability: 40000+PCS+Month
Detail Information
Place of Origin:
CHINA
Certification:
CE,ROHS,ISO
Holding Torque:
440mN.m
Lead Wire:
4
Length:
48mm
Rated Current:
1.68A
Rated Voltage:
12V
Gear Reduction Ratio:
99.5:1
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Packaging Details:
Carton:36x29x14cm
Highlight:

0.44mN.m Planetary Gearbox Stepper Motor

,

Planetary Gearbox Stepper Motor

,

NEMA17 Planetary Gearbox Stepper Motor

Product Description

Stepper motors can be programmed to achieve complex motion control, providing flexibility for automation and robotics technology.

Stepper motors can withstand large loads in a short period of time, which gives them an advantage in situations where they need to withstand large loads.



Features:

  • Bipolar or unipolar versions available

  • We offer custom services and accept contract manufacturing. Wanted dealers! !

  • Afford “a variety of international certifications” for advanced technology and electronic sector apparatus

  • Professional drivetrain solution specialist

  • Customizations on request

Dimensions

NEMA17 Ratio 99.5/1 Planetary Gearbox Stepper Motor 0.44mN.m For Cnc Robot Arm 0







Motor Specifications



Step Angel



1.8 °

Fram Size



42 mm

Number of Phase



2 Phase

Rated Current



1.68 A

Holding Torque



440 mN.m

Resistance



1.65 hm

Inductance



2.8 mH

Rotor Inertia



38 g-cm²

Motor weight



0.56 kg

Gear Reduction Ratio





99.5:1

Connection



Bipolar



Operating Specifications



Motor



Step Angle: 1.8°

Maximum  Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min



Gear Box



Housing Material:Metal
Bearing at Output:Ball Bearings
Max.Radial Load(12mm from flange):≤80N
Max.Shaft Axial Load:≤30N
Radial Play of Shaft (near to Flange):≤0.06mm
Axial Play of Shaft:≤0.3mm
Backlash at No-load:1.5°











Torque Curves







Submodels

Motor Length Length of Gearbox Raio Efficiency
34 mm

40 mm

48 mm

60 mm
27.2 mm 3.71 90%
5.18
35 mm 13.76 80%
19.2
26.8
42.7 mm 51 70%
71
99.5
139


Download





If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
            Encoder          |               Brake           |              Gearbox            |           Shaft

NEMA17 Ratio 99.5/1 Planetary Gearbox Stepper Motor 0.44mN.m For Cnc Robot Arm 1 NEMA17 Ratio 99.5/1 Planetary Gearbox Stepper Motor 0.44mN.m For Cnc Robot Arm 2 NEMA17 Ratio 99.5/1 Planetary Gearbox Stepper Motor 0.44mN.m For Cnc Robot Arm 3 NEMA17 Ratio 99.5/1 Planetary Gearbox Stepper Motor 0.44mN.m For Cnc Robot Arm 4





Please click the "Get  a quote" button below to tell us your requirements.
