NEMA 34 Stepping Motor With Broke 10.6N.m 8 Wire For Textile Machinery

NEMA 34 Stepping Motor With Broke 10.6N.m 8 Wire For Textile Machinery

Brand Name:	Casun
Model Number:	86SHD8503-37BH-HP86
MOQ:	1PC
Price:	$24.92-$25.96
Payment Terms:	D/A, T/T, L/C, D/P
Supply Ability:	40000+PCS+Month

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

CE,ROSH,ISO

Step Angel:

1.8°

Holding Torque:

10.6N.m Max

Current:

5.7A Max

Motor Length:

150mm

Shaft:

Keyway Shaft 32mm Length

Packaging Details:

Carton:36x29x14cm

Highlight:

8 Wire NEMA 34 Stepping Motor

Textile Machinery NEMA 34 Stepping Motor

10.6N.m NEMA 34 Stepping Motor

Product Description

NEMA 34 Stepping Motor With Brake 10.6N.m 8 Wire For Textile Machinery

Suitable for various mechanical and automation equipment, such as CNC machine tools, packaging machinery, textile machinery, etc. The braking function of the stepper motor can quickly stop the motor when needed.

Key Features

We welcome contract manufacturing partnerships

Enjoy a ten-year warranty and purchase with confidence

Combining proficient R&D with dedicated manufacturing processes

Expect to hear from our engineers within 48 hours with the best solution for your needs

Specialist in professional drivetrain solutions

Dimensions

Motor Specifications

Step Angle	1.8°
Frame Size	86 mm
Number of Phase	2 Phase
Rated Current	5.7 A max
Holding Torque	10.6N.m max
Resistance	0.42 ohm
Inductance	4.7 mH
Rotor Inertia	3600 g-cm²
Motor Weight	5.0 kg
Number of Leads	8
Connection	Bipolar

Operating Specifications

Step Angle	1.8°
Maximum Temperature	80°C maximum
Ambient Temperature	-20°C to 50°C
Storage Temperature	-20°C to 100°C
Humidity Range	85% or less, non-condensing
Magnet Wire Insulation	Class B 130 deg C
Insulation Resistance	100M Ohm at 500 VDC
Dielectric Strength	500 VDC for 1 min

Submodels

Model	Holding Torque	Step Angle	Length	Type of Shaft	Rated Current
86SHD4003-32	4.0N.m	1.8°	69mm	Key Shaft-32mm	4.0A
86SHD4101-32	4.5N.m	1.8°	76mm	Key Shaft-32mm	4.0A
86SHD4201-37	5.6N.m	1.8°	98mm	Key Shaft-37mm	4.0A
86SHD4314-37	6.8N.m	1.8°	112mm	Key Shaft-37mm	5.0A
86SHD4404-37	8.0N.m	1.8°	127mm	Key Shaft-37mm	5.0A
86SHD4505-37	12.0N.m	1.8°	150mm	Key Shaft-37mm	5.5A

Custom Motor Solutions

If our standard motor cannot meet your needs, we can customize the motor according to your requirements. Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Available Options

Encoder

Brake

Gearbox

Shaft

Please click the "Get a quote" button below to tell us your requirements.
