Dual Shaft 1.8 Degree 4 Phase 1.26N.m DC NEMA 23 Hybrid Stepper Motor CNC Robot

name

Dual Shaft 1.8 Degree 4 Phase 1.26N.m DC NEMA 23 Hybrid Stepper Motor CNC Robot

Brand Name: Casun
Model Number: 57SHD8409-21SH
MOQ: 1PC
Price: $3.14-$5
Payment Terms: D/A, T/T, L/C, D/P
Supply Ability: 40000+PCS+Month
Detail Information
Product Description
Detail Information
Place of Origin:
CHINA
Certification:
CE,ROHS,ISO
Step Angel:
1.8°
Holding Torque:
1.26N.m
Current:
4.24A
Motor Length:
56mm
Shaft:
Dual Shaft 21mm Length
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Packaging Details:
Carton:36x29x14cm
Highlight:

1.26N.m Dual Shaft Stepper Motor

,

CNC Robot Dual Shaft Stepper Motor

,

4 Phase Dual Shaft Stepper Motor

Product Description

Complex motion control and automation tasks can be programmed through microcontrollers or other control devices.

Suitable for various industries and fields, such as industrial automation, robotics, 3D printing, medical devices, etc.



Features:

  • High torque and high precision

  • Professional drivetrain solution specialist

  • With 12 years of experience in China, we have served over 800 customers

  • Ten-year warranty, buy with confidence

  • Each model of stepper motor is designed for different applications

Appearance

Dual Shaft 1.8 Degree 4 Phase 1.26N.m DC NEMA 23 Hybrid Stepper Motor CNC Robot 0

Dimensions

Dual Shaft 1.8 Degree 4 Phase 1.26N.m DC NEMA 23 Hybrid Stepper Motor CNC Robot 1

Motor Specifications



Step Angel

1.8 °

Fram Size

57 mm

Number of Phase

4 Phase

Rated Current

4.24 A

Holding Torque

1.26 N.m

Resistance

0.375 ohm

Inductance

1.1 mH

Rotor Inertia

300 g-cm²

Motor weight

0.7 kg

Number of leads

8

Connection

Bipolar

Operating Specifications

Step Angle: 1.8°

Maximum  Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min







Torque Curves













Submodels



Model Holding Torque Step Angle Length Type of Shaft Rated Current
57SHD4013-21B 0.6N.m 1.8° 41mm D Shaft-21mm 1.0A
57SHD4415-21B 1.1N.m 1.8° 54mm D Shaft-21mm 3.0A
57SHD4816-21B 2.0N.m 1.8° 76mm D Shaft-21mm 3.0A
57SHD4913-21B 2.5N.m 1.8° 83mm D Shaft-21mm 3.0A
57SHD4934-20B 3.0N.m 1.8° 100mm D Shaft-20mm 3.0A



Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:

Encoder

Brake

Gearbox

Shaft
Dual Shaft 1.8 Degree 4 Phase 1.26N.m DC NEMA 23 Hybrid Stepper Motor CNC Robot 2 Dual Shaft 1.8 Degree 4 Phase 1.26N.m DC NEMA 23 Hybrid Stepper Motor CNC Robot 3 Dual Shaft 1.8 Degree 4 Phase 1.26N.m DC NEMA 23 Hybrid Stepper Motor CNC Robot 4 Dual Shaft 1.8 Degree 4 Phase 1.26N.m DC NEMA 23 Hybrid Stepper Motor CNC Robot 5



Please click the "Get a quote" button below to tell us your requirements.



Tags:

1.26N.m Dual Shaft Stepper Motor

CNC Robot Dual Shaft Stepper Motor

4 Phase Dual Shaft Stepper Motor
