Stepper Motor 42mm body 360mN.m 1.5A for image scanners and precision positioning tools

Stepper Motor 42mm body 360mN.m 1.5A for image scanners and precision positioning tools

Brand Name:	CASUN
Model Number:	P35SHD0817-150NT
MOQ:	1pcs-10pcs
Price:	$4.54/pcs - $6.34/pcs
Payment Terms:	L/C, D/A, T/T
Supply Ability:	40000+PCS+Month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE,ROHS,ISO

Step Angle:

1.8degree

Phase:

Rated Voltage:

4.8V

Rate Current:

1.5A

Holding Torque:

360mN.m

Customized:

The Motor Can Be Designed &manufactured With Customized Request.

Packaging Details:

Carton:38x29xc14m

Highlight:

42mm body Stepper Motor

360mN.m Stepper Motor

42mm Stepper Motor

Product Description

Stepper Motor 42mm Body 360mN.m 1.5A for Image Scanners and Precision Positioning Tools

The 42mm Hybrid Stepper Motor Series offers powerful holding torque in a variety of sizes. Use with a microstepping driver to reduce vibration and achieve higher step resolution.

Key Features

Structured information hierarchy for better readability
Emphasized global reach and technical capabilities with custom services
Established in China for 12 years with over 800 customers served
Ten-year warranty for purchase confidence

Dimensions

Motor Specifications

Step Angle	1.8°
Frame Size	42 mm
Number of Phase	2 Phase
Rated Current	1.5 A
Resistance	3.2 Ohm
Inductance	4.5 mH
Rotor Inertia	57 g-cm²
Motor Weight	0.24 kg
Connection	Bipolar

Operating Specifications

Step Angle: 1.8°
Maximum Temperature: 80°C maximum
Ambient Temperature: -20°C to 50°C
Storage Temperature: -20°C to 100°C
Humidity Range: 85% or less, non-condensing
Magnet Wire Insulation: Class B 130°C
Insulation Resistance: 100M Ohm at 500 VDC
Dielectric Strength: 500 VDC for 1 min
Shaft Radial Play: 0.02Max. (450g-load)
Shaft Axial Play: 0.08Max. (450g-load)
Max. radial force: 28N (20mm from the flange)
Max. axial force: 10N

Custom Motor Solutions

If our standard motor cannot meet your needs, we can customize the motor according to your requirements.

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, travel, linear travel per step, and more.

Frequently Asked Questions

Who are we?

We are based in Guangdong, China, established in 2011. We serve Domestic Market (63.00%), Western Europe (12.00%), North America (9.00%), Eastern Asia (8.00%), and other global markets. Our office has 51-100 employees.

How can we guarantee quality?

Always provide a pre-production sample before mass production and conduct final inspection before shipment.

What can you buy from us?

Stepper Motor, BLDC Motor

Why should you buy from us instead of other suppliers?

We specialize in producing and selling stepper motors for more than 11 years.

What services can we provide?

Accepted Delivery Terms: FOB, CFR, CIF, EXW, Express Delivery
Accepted Payment Currency: USD, CNY
Accepted Payment Type: T/T, L/C, D/P D/A, PayPal
Languages Spoken: English, Chinese, Japanese
