Casun Nema 23 Factory Prices 780mN.m 3.4V High Tough Hybrid Stepper Motor for CNC

name

Casun Nema 23 Factory Prices 780mN.m 3.4V High Tough Hybrid Stepper Motor for CNC

Brand Name: Casun
Model Number: 57SHD0048B-20B
MOQ: 5PC
Price: $6.02~$7.38
Payment Terms: D/A, T/T, L/C, D/P
Supply Ability: 10000+PCS+Month
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
CE,ROHS,ISO
Holding Torque:
780 MN.m
Voltage:
3.4V
Current:
2.4A
Body Length:
41mm
Weight:
0.45 Kg
Phase Resistance:
1.2 Ohm ±10% （At 20℃）
Shaft Length:
20 Mm
Phase:
2
Insulation Class:
Class B
Packaging Details:
Carton:38x29x18cm
Product Description

Casun Nema 23 Factory Prices 780mN.m 3.4V High Tough Hybrid Stepper Motor for CNC

A high-torque Nema 23 stepper motor delivering 780mN.m holding torque at 3.4V for robust performance in demanding CNC, milling, and industrial automation applications. Built for durability and precision, this motor ensures smooth operation and reliable positioning.



Features:

  • Bipolar or unipolar versions available

  • Hybrid stepper construction

  • Available in single or double shaft versions

  • CE and RoHS approved

  • Customizations on request

Dimensions

                    Casun Nema 23 Factory Prices 780mN.m 3.4V High Tough Hybrid Stepper Motor for CNC 0



Motor Specifications



Step Angel



 1.8°

Frame Size



 41 mm

Number of Phase



 2 Phase

Rated Current



 2.4 Amp

Holding Torque



 780 mN.m

Resistance



 1.2 ohm

Inductance



 3.1 mH

Rotor Inertia



 170 g.cm²

Motor weight



 0.45 kg

Connection



 Bipolar



Operating Specifications



Motor



Step Angle: 1.8°

Maximum Temperature: 80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range: 85% or less, non-condensing

Magnet Wire Insulation: Class B 130 deg C

Insulation Resistance: 100M Ohm at 500 VDC

Dielectric Strength: 500 VDC for 1 min



Encoder







Voltage: 5 v

Output: A + A - B + B - Z + Z -



Submodels



                    Casun Nema 23 Factory Prices 780mN.m 3.4V High Tough Hybrid Stepper Motor for CNC 1



Download



If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Shaft

Casun Nema 23 Factory Prices 780mN.m 3.4V High Tough Hybrid Stepper Motor for CNC 2 Casun Nema 23 Factory Prices 780mN.m 3.4V High Tough Hybrid Stepper Motor for CNC 3 Casun Nema 23 Factory Prices 780mN.m 3.4V High Tough Hybrid Stepper Motor for CNC 4 Casun Nema 23 Factory Prices 780mN.m 3.4V High Tough Hybrid Stepper Motor for CNC 5





Please click the "Get a quote" button below to tell us your requirements.
