Casun Linear Stepper Motor With 0.8 Kg At 600 PPS 1.8° Degree Nema 8 High Precision Stepper Motor

Brand Name:	Casun
Model Number:	B20SHD4351-C9P
MOQ:	5PC
Price:	$16.8~$19
Payment Terms:	D/A, T/T, L/C, D/P
Supply Ability:	10000+PCS+Month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE,ROHS,ISO

Holding Torque:

0.8 Kg At 600 PPS

Voltage:

2.55 V

Current:

0.5 A

Body Length:

28mm

Weight:

0.1 Kg

Phase Resistance:

5.1 Ohm ±10% （At 20℃）

Shaft Length:

23 Mm

Phase:

Insulation Class:

Class B

Packaging Details:

Carton:38x29x18cm

Highlight:

600 PPS Linear Stepper Motor

1.8° Degree Linear Stepper Motor

High Precision Linear Stepper Motor

Product Description

Casun Linear Stepper Motor With 0.8 Kg At 600 PPS 1.8° Degree Nema 8 High Precision Stepper Motor

The Casun NEMA 8 Linear Stepper Motor delivers high precision (1.8° step angle) and smooth motion, with a thrust force of 0.8 kg at 600 PPS. Compact yet powerful, it's ideal for applications requiring accurate positioning in tight spaces, such as medical devices, lab automation, and small CNC systems. Engineered for reliability and efficiency, this motor ensures consistent performance in precision-driven tasks.

Key Features

Bipolar or unipolar versions available
Hybrid stepper construction
Available in single- or double-shaft versions
CE and RoHS approved
Customizations on request

Dimensions

Motor Specifications

Step Angle	1.8°
Frame Size	28 mm
Number of Phase	2 Phase
Rated Current	0.5 Amp
Holding Torque	0.8 kg at 600 PPS
Resistance	5.1 ohm
Inductance	1.5 mH
Rotor Inertia	2 g.cm²
Motor Weight	0.1 kg
Connection	Bipolar

Operating Specifications

Motor

Step Angle	1.8°
Maximum Temperature	80°C maximum
Ambient Temperature	-20°C to 50°C
Storage Temperature	-20°C to 100°C
Humidity Range	85% or less, non-condensing
Magnet Wire Insulation	Class B 130°C
Insulation Resistance	100M Ohm at 500 VDC
Dielectric Strength	500 VDC for 1 min

Encoder

Voltage	5V
Output	A + A - B + B - Z + Z -

Submodels

Custom Motor Solutions

If our standard motor cannot meet your needs, we can customize the motor according to your requirements.

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Available Options

Please click the "Get a quote" button below to tell us your requirements.
