Nema 34 Hybrid Stepper Motor with Brake 24V DC 4.5N.m Big Tough CE RoHS Certificated from Casun Motor

name

Nema 34 Hybrid Stepper Motor with Brake 24V DC 4.5N.m Big Tough CE RoHS Certificated from Casun Motor

Brand Name: Casun
Model Number: 86SHD4101-160NK-EB0505
MOQ: 5PC
Price: $46-50$
Payment Terms: D/A,T/T,L/C,D/P
Supply Ability: 10000+PCS+Month
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
CE,ROHS,ISO
Holding Torque:
4.5 N.m
Voltage:
3.48 V
Current:
4 A
Body Length:
110 Mm
Weight:
2.3 Kg
Phase Resistance:
0.87 Ohm ±10% （At 20℃）
Shaft Length:
160 Mm
Phase:
2
Insulation Class:
Class B
Packaging Details:
Carton:38x29x18cm
Highlight:

NEMA 34 stepper motor with brake

,

24V DC hybrid stepper motor

,

CE certified NEMA 34 motor

Product Description
Nema 34 Hybrid Stepper Motor with Brake 24V DC 4.5 N.m

This rugged NEMA 34 hybrid stepper motor from Casun Motor delivers high torque (4.5 N.m) and reliable braking performance for industrial applications. Operating at 24V DC, this motor is built for demanding environments while meeting CE & RoHS certifications.

Key Features
  • Bipolar or unipolar versions available
  • Hybrid stepper construction
  • Available in single or double shaft versions
  • CE and RoHS approved
  • Customizations available on request
Technical Specifications
Attribute Value
Holding Torque 4.5 N.m
Voltage 3.48 V
Current 4 A
Body Length 110 mm
Weight 2.3 kg
Phase Resistance 0.87 ohm ±10% (At 20℃)
Shaft Length 160 mm
Phase 2
Insulation Class Class B
Motor Dimensions
Nema 34 Hybrid Stepper Motor with Brake 24V DC 4.5N.m Big Tough CE RoHS Certificated from Casun Motor 0
Operating Specifications
Motor
  • Step Angle: 1.8°
  • Maximum Temperature: 80°C maximum
  • Ambient Temperature: -20°C to 50°C
  • Storage Temperature: -20°C to 100°C
  • Humidity Range: 85% or less, non-condensing
  • Magnet Wire Insulation: Class B 130°C
  • Insulation Resistance: 100M Ohm at 500 VDC
  • Dielectric Strength: 500 VDC for 1 min
Encoder
  • Voltage: 5V
  • Output: A + A - B + B - Z + Z -
Available Submodels
Nema 34 Hybrid Stepper Motor with Brake 24V DC 4.5N.m Big Tough CE RoHS Certificated from Casun Motor 1
Customization Options

If our standard motor cannot meet your requirements, we can customize the motor according to your specific needs. Customized content includes but is not limited to:

  • Special shafts
  • Custom winding parameters
  • Modified installation dimensions
  • Special lead wire requirements
  • Custom connectors
Available Options
Nema 34 Hybrid Stepper Motor with Brake 24V DC 4.5N.m Big Tough CE RoHS Certificated from Casun Motor 2 Nema 34 Hybrid Stepper Motor with Brake 24V DC 4.5N.m Big Tough CE RoHS Certificated from Casun Motor 3 Nema 34 Hybrid Stepper Motor with Brake 24V DC 4.5N.m Big Tough CE RoHS Certificated from Casun Motor 4 Nema 34 Hybrid Stepper Motor with Brake 24V DC 4.5N.m Big Tough CE RoHS Certificated from Casun Motor 5

Please click the "Get a quote" button below to tell us your specific requirements.
