【42SHD4261】1.68A NEMA 17 Stepper Motor 40mm body Micro Motor 450mN.m for Home Intelligence
  • 【42SHD4261】1.68A NEMA 17 Stepper Motor 40mm body Micro Motor 450mN.m for Home Intelligence
  • 【42SHD4261】1.68A NEMA 17 Stepper Motor 40mm body Micro Motor 450mN.m for Home Intelligence
  • 【42SHD4261】1.68A NEMA 17 Stepper Motor 40mm body Micro Motor 450mN.m for Home Intelligence
  • 【42SHD4261】1.68A NEMA 17 Stepper Motor 40mm body Micro Motor 450mN.m for Home Intelligence

【42SHD4261】1.68A NEMA 17 Stepper Motor 40mm body Micro Motor 450mN.m for Home Intelligence

Place of Origin CHINA
Brand Name Casun
Certification CE,ROSH,ISO
Model Number 42SHD4261-20H
Product Details
Step Angel:
1.8°
Holding Torque:
450mN.m
Current:
1.68A
Motor Length:
40mm
Shaft:
Round Shaft 24mm Length
Payment & Shipping Terms
Minimum Order Quantity
1PC
Price
$3.14-$5
Packaging Details
Carton:36x29x14cm
Delivery Time
7-15 days
Payment Terms
D/A, T/T, L/C, D/P
Supply Ability
40000+PCS+Month
Product Description

The 42mm Hybrid Stepper Motor Series offers powerful holding torque in a variety of sizes.

Use with a microstepping driver to reduce vibration and achieve higher step resolution.

Choose a baseline version or request your own customized configuration.



Features:

  • Bipolar or unipolar versions available

  • Hybrid stepper construction

  • Available in single or double shaft versions

  • CE and RoHS approved

  • Customizations on request

Appearance

【42SHD4261】1.68A NEMA 17 Stepper Motor 40mm body Micro Motor 450mN.m for Home Intelligence 0

Dimensions

【42SHD4261】1.68A NEMA 17 Stepper Motor 40mm body Micro Motor 450mN.m for Home Intelligence 1



Motor Specifications



Step Angel

1.8 °

Fram Size

40 mm

Number of Phase

2 Phase

Rated Current

1.68 A

Holding Torque

450 mN.m

Resistance

2.0 ohm

Inductance

4.4 mH

Rotor Inertia

57 g-cm²

Motor weight

0.3 kg

Number of leads

4

Connection

Bipolar

Operating Specifications

Step Angle: 1.8°

Maximum  Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min







Torque Curves













Submodels

Model Holding Torque Step Angle Motor Length Type of Shaft Rated Current
42SHD4950 0.13N.m 1.8° 20mm D Shaft-20mm 1.0A
42SHD4003 0.26N.m 1.8° 34mm D Shaft-20mm 0.4A
42SHD0261 0.45N.m 1.8° 40mm D Shaft-20mm 1.68A
42SHD4425 0.59N.m 1.8° 48mm D Shaft-24mm 2.0A
42SHD4813 0.8N.m 1.8° 60mm D Shaft-24mm 2.1A





Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:

Encoder

Brake

Gearbox

Shaft

【42SHD4261】1.68A NEMA 17 Stepper Motor 40mm body Micro Motor 450mN.m for Home Intelligence 2 【42SHD4261】1.68A NEMA 17 Stepper Motor 40mm body Micro Motor 450mN.m for Home Intelligence 3 【42SHD4261】1.68A NEMA 17 Stepper Motor 40mm body Micro Motor 450mN.m for Home Intelligence 4 【42SHD4261】1.68A NEMA 17 Stepper Motor 40mm body Micro Motor 450mN.m for Home Intelligence 5



Please click the "Get a quote" button below to tell us your requirements.



CONTACT US AT ANY TIME

86--13539447986
NO.61 Pingxi Industrial Zone, Huashan Town, Huadu District, GUANGZHOU, 510880,China
Send your inquiry directly to us
