Product Details
Place of Origin: CHINA
Brand Name: Casun
Certification: CE,ROHS,ISO
Model Number: 42SHD4244-24B
Payment & Shipping Terms
Minimum Order Quantity: 1PC
Price: $3.14-$5
Packaging Details: Carton:36x29x14cm
Delivery Time: 7-15 days
Payment Terms: D/A, T/T, L/C, D/P
Supply Ability: 40000+PCS+Month
Step Angel: |
1.8° |
Holding Torque: |
450mN.m |
Current: |
2.0A |
Motor Length: |
40mm |
Shaft: |
Milling Flat Shaft 24mm Length |
Customized: |
The Motor Can Be Designed &manufactured With Customized Request. |
Step Angel: |
1.8° |
Holding Torque: |
450mN.m |
Current: |
2.0A |
Motor Length: |
40mm |
Shaft: |
Milling Flat Shaft 24mm Length |
Customized: |
The Motor Can Be Designed &manufactured With Customized Request. |
The 42mm stepper motor has a longer lifespan and lower failure rate, thereby increasing the reliability of the equipment.
It has been widely applied in fields such as industrial automation, robotics, textiles, and printing.
Features:
Step Angel |
1.8 ° |
Fram Size |
40 mm |
Number of Phase |
2 Phase |
Rated Current |
2.0 A |
Holding Torque |
450 mN.m |
Resistance |
1.1 ohm |
Inductance |
2.6 mH |
Rotor Inertia |
57 g-cm² |
Motor weight |
0.3 kg |
Number of leads |
4 |
Connection |
Bipolar |
Step Angle: 1.8°
Maximum Temperature :80°C maximum
Ambient Temperature: -20 °C to 50°C
Storage Temperature -20: °C to 100°C
Humidity Range (%) :85% or less, non-condensing
Magnet Wire Insulation :Class B 130 deg C
Insulation Resistance :100M Ohm at 500 VDC
Dielectric Strength :500 VDC for 1 min
Model | Holding Torque | Step Angle | Motor Length | Type of Shaft | Rated Current |
42SHD4950 | 0.13N.m | 1.8° | 20mm | D Shaft-20mm | 1.0A |
42SHD4003 | 0.26N.m | 1.8° | 34mm | D Shaft-20mm | 0.4A |
42SHD0261 | 0.45N.m | 1.8° | 40mm | D Shaft-20mm | 1.68A |
42SHD4425 | 0.59N.m | 1.8° | 48mm | D Shaft-24mm | 2.0A |
42SHD4813 | 0.8N.m | 1.8° | 60mm | D Shaft-24mm | 2.1A |
