products details

Created with Pixso. Home Created with Pixso. Products Created with Pixso.
Hybrid Stepper Motor
Created with Pixso.

NEMA 17 Bipolar 2 Phase 1.8 1.2A 6.6V 2 Phase Stepper Motor for Stage Light Medical Equipment

name

NEMA 17 Bipolar 2 Phase 1.8 1.2A 6.6V 2 Phase Stepper Motor for Stage Light Medical Equipment

Brand Name: Casun
Model Number: 42SHD4287-24BH
MOQ: 1PC
Price: $3.14-$5
Payment Terms: D/A, T/T, L/C, D/P
Supply Ability: 40000+PCS+Month
Detail Information
Product Description
Detail Information
Place of Origin:
CHINA
Certification:
CE,ROHS,ISO
Step Angel:
1.8°
Holding Torque:
500mN.m
Current:
1.2A
Motor Length:
40mm
Shaft:
Milling Flat Shaft 20mm Length
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Packaging Details:
Carton:36x29x14cm
Highlight:

1.2A NEMA 17 Stepper Motor

,

6.6V NEMA 17 Stepper Motor

Product Description

The 42mm stepper motors typically have stronger structural and material durability, capable of withstanding larger loads and long-term operation.

Use with a microstepping driver to reduce vibration and achieve higher step resolution.



Features:

  • High torque and high precision

  • Accept contract manufacturing

  • For high-tech industry and electronic industry equipment

  • Expert manufacturing research and development

  • Superior accuracy and torque





Motor Specifications



Step Angel

1.8 °

Fram Size

40 mm

Number of Phase

2 Phase

Rated Current

1.2 A

Holding Torque

500 mN.m

Resistance

5.5 ohm

Inductance

11 mH

Rotor Inertia

57 g-cm²

Motor weight

0.24 kg

Number of leads

4

Connection

Bipolar

Appearance

NEMA 17 Bipolar 2 Phase 1.8 1.2A 6.6V 2 Phase Stepper Motor for Stage Light Medical Equipment 0

Dimensions

NEMA 17 Bipolar 2 Phase 1.8 1.2A 6.6V 2 Phase Stepper Motor for Stage Light Medical Equipment 1
Operating Specifications

Step Angle: 1.8°

Maximum  Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min







Torque Curves













Submodels

Model Holding Torque Step Angle Motor Length Type of Shaft Rated Current
42SHD4950 0.13N.m 1.8° 20mm D Shaft-20mm 1.0A
42SHD4003 0.26N.m 1.8° 34mm D Shaft-20mm 0.4A
42SHD0261 0.45N.m 1.8° 40mm D Shaft-20mm 1.68A
42SHD4425 0.59N.m 1.8° 48mm D Shaft-24mm 2.0A
42SHD4813 0.8N.m 1.8° 60mm D Shaft-24mm 2.1A





Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:

Encoder

Brake

Gearbox

Shaft
NEMA 17 Bipolar 2 Phase 1.8 1.2A 6.6V 2 Phase Stepper Motor for Stage Light Medical Equipment 2 NEMA 17 Bipolar 2 Phase 1.8 1.2A 6.6V 2 Phase Stepper Motor for Stage Light Medical Equipment 3 NEMA 17 Bipolar 2 Phase 1.8 1.2A 6.6V 2 Phase Stepper Motor for Stage Light Medical Equipment 4 NEMA 17 Bipolar 2 Phase 1.8 1.2A 6.6V 2 Phase Stepper Motor for Stage Light Medical Equipment 5



Please click the "Get a quote" button below to tell us your requirements.



Tags:

2 Phase Bipolar Stepper Motor

Nema 6 Bipolar Stepper Motor

1.2A NEMA 17 Stepper Motor
