Product Details
Place of Origin: CHINA
Brand Name: Casun
Certification: CE,ROSH,ISO
Model Number: 42SHD0810-20B
Payment & Shipping Terms
Minimum Order Quantity: 1PC
Price: $3.14-$5
Packaging Details: Carton:36x29x14cm
Delivery Time: 7-15 days
Payment Terms: D/A, T/T, L/C, D/P
Supply Ability: 40000+PCS+Month
Step Angel: |
1.8° |
Holding Torque: |
1100mN.m |
Current: |
0.5A |
Motor Length: |
60mm |
Shaft: |
Milling Flat Shaft 25mm Length |
Customized: |
The Motor Can Be Designed &manufactured With Customized Request. |
Step Angel: |
1.8° |
Holding Torque: |
1100mN.m |
Current: |
0.5A |
Motor Length: |
60mm |
Shaft: |
Milling Flat Shaft 25mm Length |
Customized: |
The Motor Can Be Designed &manufactured With Customized Request. |
NEMA 17 stepper motors are used to precisely control the position of cutting tools or heads, achieving precise engraving and cutting.
Automation equipment, precision positioning systems, robots, electronic devices, etc.
Features:
Step Angel |
1.8 ° |
Fram Size |
42 mm |
Number of Phase |
2 Phase |
Rated Current |
2.5 A |
Holding Torque |
1100 mN.m |
Resistance |
1.7 ohm |
Inductance |
4.9 mH |
Rotor Inertia |
102 g-cm² |
Motor weight |
0.48 kg |
Number of leads |
4 |
Connection |
Bipolar |
Step Angle: 1.8°
Maximum Temperature :80°C maximum
Ambient Temperature: -20 °C to 50°C
Storage Temperature -20: °C to 100°C
Humidity Range (%) :85% or less, non-condensing
Magnet Wire Insulation :Class B 130 deg C
Insulation Resistance :100M Ohm at 500 VDC
Dielectric Strength :500 VDC for 1 min
Model | Holding Torque | Step Angle | Motor Length | Type of Shaft | Rated Current |
42SHD4950 | 0.13N.m | 1.8° | 20mm | D Shaft-20mm | 1.0A |
42SHD4003 | 0.26N.m | 1.8° | 34mm | D Shaft-20mm | 0.4A |
42SHD0261 | 0.45N.m | 1.8° | 40mm | D Shaft-20mm | 1.68A |
42SHD4425 | 0.59N.m | 1.8° | 48mm | D Shaft-24mm | 2.0A |
42SHD4813 | 0.8N.m | 1.8° | 60mm | D Shaft-24mm | 2.1A |
