2.7V 0.6N.M Nema 17 Stepping Motor For XYZ Measuring Instrument

name

2.7V 0.6N.M Nema 17 Stepping Motor For XYZ Measuring Instrument

Brand Name: Casun
Model Number: 42SHD0801-25B
MOQ: 1PC
Price: $3.14-$5
Payment Terms: D/A, T/T, L/C, D/P
Supply Ability: 40000+PCS+Month
Detail Information
Product Description
Detail Information
Place of Origin:
CHINA
Certification:
CE,ROSH,ISO
Step Angel:
1.8°
Holding Torque:
600mN.m
Current:
1.5A
Motor Length:
60mm
Shaft:
Milling Flat Shaft 25mm Length
Customized:
The Motor Can Be Designed &manufactured With Customized Request.
Packaging Details:
Carton:36x29x14cm
Highlight:

2.7V 0.6N.M Nema 17

,

0.6N.M Nema 17 Stepping Motor

,

2.7V Casun Stepper Motor

Product Description
2.7V 0.6N.M Nema 17 Stepping Motor For XYZ Measuring Instrument
By applying a pulse signal to control the rotation of the rotor, for each pulse received, the rotor will rotate by a certain angle. Use with a microstepping driver to reduce vibration and achieve higher step resolution.
Key Features
  • High torque and high precision
  • Designed for high-tech industry and electronic industry equipment
  • Accept contract manufacturing
  • Multiple international certifications available
  • Our engineers will contact you within 48 hours to provide the best solution
Product Details
Appearance
2.7V 0.6N.M Nema 17 Stepping Motor For XYZ Measuring Instrument 0
Dimensions
2.7V 0.6N.M Nema 17 Stepping Motor For XYZ Measuring Instrument 1
Motor Specifications
Step Angle 1.8°
Frame Size 42 mm
Number of Phase 2 Phase
Rated Current 1.5 A
Holding Torque 600 mN.m
Resistance 1.8 ohm
Inductance 3.2 mH
Rotor Inertia 102 g-cm²
Motor Weight 0.45 kg
Number of Leads 4
Connection Bipolar
Operating Specifications
Step Angle 1.8°
Maximum Temperature 80°C maximum
Ambient Temperature -20°C to 50°C
Storage Temperature -20°C to 100°C
Humidity Range 85% or less, non-condensing
Magnet Wire Insulation Class B 130°C
Insulation Resistance 100M Ohm at 500 VDC
Dielectric Strength 500 VDC for 1 min
Available Models
Model Holding Torque Step Angle Motor Length Type of Shaft Rated Current
42SHD4950 0.13N.m 1.8° 20mm D Shaft-20mm 1.0A
42SHD4003 0.26N.m 1.8° 34mm D Shaft-20mm 0.4A
42SHD0261 0.45N.m 1.8° 40mm D Shaft-20mm 1.68A
42SHD4425 0.59N.m 1.8° 48mm D Shaft-24mm 2.0A
42SHD4813 0.8N.m 1.8° 60mm D Shaft-24mm 2.1A
Customization Options
If our standard motor cannot meet your needs, we can customize the motor according to your requirements.
Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.
2.7V 0.6N.M Nema 17 Stepping Motor For XYZ Measuring Instrument 2
Encoder
2.7V 0.6N.M Nema 17 Stepping Motor For XYZ Measuring Instrument 3
Brake
2.7V 0.6N.M Nema 17 Stepping Motor For XYZ Measuring Instrument 4
Gearbox
2.7V 0.6N.M Nema 17 Stepping Motor For XYZ Measuring Instrument 5
Shaft
Please click the "Get a quote" button below to tell us your requirements.
