Unipolar Nema 17 Cnc Router 1.7A 60mm 3018 Cnc Stepper Motor

Unipolar Nema 17 Cnc Router 1.7A 60mm 3018 Cnc Stepper Motor

Brand Name:	Casun
Model Number:	42SHD0828-24B
MOQ:	1PC
Price:	$3.14-$5
Payment Terms:	D/A, T/T, L/C, D/P
Supply Ability:	40000+PCS+Month

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

CE,ROSH,ISO

Step Angel:

1.8°

Holding Torque:

650mN.m

Current:

1.7A

Motor Length:

60mm

Shaft:

Milling Flat Shaft 24mm Length

Customized:

The Motor Can Be Designed &manufactured With Customized Request.

Customized:

The Motor Can Be Designed &manufactured With Customized Request.

Packaging Details:

Carton:36x29x14cm

Highlight:

Unipolar Nema 17 Cnc Router

60mm 3018 Cnc Stepper Motor

Nema 17 Cnc Router 1.7A

Product Description

Unipolar Nema 17 Cnc Router 1.7A 60mm 3018 Cnc Stepper Motor

Among various analytical instruments in the laboratory, the NEMA 17 stepper motor is used to move sample trays, adjust lens focal length, and other precision applications. NEMA 17 stepper motors typically offer excellent value with lower costs.

Key Features

High torque and high precision
Ideal for high-tech industry and electronic industry equipment
Backed by a 10-year warranty for your confident purchase
Multiple international certifications
Expert in drivetrain solutions

Appearance

Dimensions

Motor Specifications

Step Angle	1.8°
Frame Size	42 mm
Number of Phase	2 Phase
Rated Current	1.7 A
Holding Torque	650 mN.m
Resistance	1.5 ohm
Inductance	2.8 mH
Rotor Inertia	102 g-cm²
Motor Weight	0.48 kg
Number of Leads	4
Connection	Bipolar

Operating Specifications

Step Angle: 1.8°

Maximum Temperature: 80°C maximum

Ambient Temperature: -20°C to 50°C

Storage Temperature: -20°C to 100°C

Humidity Range: 85% or less, non-condensing

Magnet Wire Insulation: Class B 130°C

Insulation Resistance: 100M Ohm at 500 VDC

Dielectric Strength: 500 VDC for 1 min

Available Models

Model	Holding Torque	Step Angle	Motor Length	Type of Shaft	Rated Current
42SHD4950	0.13N.m	1.8°	20mm	D Shaft-20mm	1.0A
42SHD4003	0.26N.m	1.8°	34mm	D Shaft-20mm	0.4A
42SHD0261	0.45N.m	1.8°	40mm	D Shaft-20mm	1.68A
42SHD4425	0.59N.m	1.8°	48mm	D Shaft-24mm	2.0A
42SHD4813	0.8N.m	1.8°	60mm	D Shaft-24mm	2.1A

Customization Options

If our standard motor cannot meet your needs, we can customize the motor according to your requirements. Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, and more.

Encoder

Brake

Gearbox

Shaft

Please click the button below to tell us your requirements and get a customized quote.
